Reference
Designator
Description Part Number Note
R701, 702, 777,
790, 711, 712, 714,
722, 729, 734, 773,
774, 775, 776, 789,
808, 812
1.0 k, 5%, 1/6 W 139168
R703 270 Ω, 5%, 1/6 W 139389
R704, 733, E35,
N11, N12, 715, 806,
E20
56 Ω, 5%, 1/6 W 139342
R705, 737, 738,
813, E33
2.2 k, 5%, 1/6 W 139178
R706 2.2 k, 5%, 1/6 W 139178
R707 330 k, 5%, 1/6 W 139390
R708, E36, N01,
N02
10 Ω, 5%, 1/6 W 139374
R709, 710 348 k, 2%, 1/4 W 139391 3
R713, 788, 814 10.0 k, 5%, 1/6 W 139169
R716, 780 22.0 k, 5%, 1/6 W 139185
R717, 830, E32,
E34, N09, N10
220 Ω, 5%, 1/6W 139163
R718 15.0 k, 5%,1/6 W 139393
R719, 720 470 k, 5%, 1/6 W 139394 3
R721, 778, 791 1.0 k, 5%, 1/6 W 139168
R723 332 k, 1%, 1/6W 139170
R724 Varistor 138998 3
R725, 726, 796 4.99 k, 1%, 1/6W 139172
R727, 728, 807, E07 10.0 k, 1%, 1/6W 139176
R730 21.0 k, 1%, 1/6W 139173
R731, E12 200 k, 1%, 1/6W 139174
R732 6.65 k, 1%, 1/6W 139175
R735, 736, 743, 799 4.7 k, 5%, 1/6W 139177
R739, 740, 741, 742 680 Ω, 5%, 1/4W 139179
R765, 766 22 Ω, 5%, 3W,
Power
136357 3
100V/120V
R765, 766 15 Ω, 5%, 5W,
Power
139181 3
230V
R767 0.1 Ω, 5%, 5W,
Power
139160 3
R768 27.0 k, 5%, 2W,
Power
136359
R771, 772 10 Ω, 5%, 1/4W 139183
R779 61.9 k, 1%, 1/6W 139184
R781, 782 390 Ω, 5%, 1/4W 139186
R783, 784, 820 100 Ω, 5%, 1/6W 139187
R785, E37 100 k, 5%, 1/6W 139188
R786 3.3 k, 5%, 1/6W 141451
R787 43.2 k, 1%, 1/6W 139189
R792, 811 47.0 k, 5%, 1/6 W 139190
R793, 794, E29 20.0 k, 1%, 1/6 W 139191
R795 4.99 k, 1 %, 1/6 W 139172
R797, 798 18.2k, 1 %, 1/6 W 139192
R801, 802, E40, E41 237 Ω, 1%, 1/6W 139161
R803, 804, E38, E39 1.21 k, 1%, 1/6W 139162
ELECTRICAL PART LIST
Resistors
