Technical Specifications
AM10
Single Module Performance
Frequency Response (–3 dB)
1
65 Hz to 15 kHz
Frequency Range (–10 dB) 55 Hz to 17 kHz
Nominal Coverage Pattern (H × V) 60° × 10° (AM10/60) or 80° × 10° (AM10/80) or 100° × 10° (AM10/100)
Recommended High-pass Filter 60 Hz with minimum 12 dB / octave
Crossover 950 Hz internal passive or external bi-amp (Bose ControlSpace presets)
70V/100V transformer tap settings 70V: 100W, 200W, 400W; 100V: 200W, 400W
Bose Extended Lifecycle Test
2
AES Transducer Test
3
LF (bi-amp) HF (bi-amp) Passive LF (bi-amp) HF (bi-amp) Passive
Power Handling, long-term continuous 600 W 150 W 750 W 750 W 200 W 900 W
Power Handling, peak 2400 W 600 W 3000 W 3000 W 800 W 3600 W
AM10/60 AM10/80 AM10/100
LF HF Passive LF HF Passive LF HF Passive
Sensitivity (SPL / 1W @ 1 m)
4
96 dB 106 dB 99 dB 96 dB 105 dB 98 dB 96 dB 104 dB 97 dB
Calculated max. SPL @ 1 m (Bose power test)
5
124 dB 128 dB 128 dB 124 dB 127 dB 127 dB 124 dB 126 dB 126 dB
Calculated max. SPL @ 1 m (2-hour power test) 125 dB 129 dB 129 dB 125 dB 128 dB 128 dB 125 dB 127 dB 127 dB
Calculated max. SPL @ 1 m (Bose power test), peak 130 dB 134 dB 134 dB 130 dB 133 dB 133 dB 130 dB 132 dB 132 dB
Calculated max. SPL @ 1 m (2-hour power test), peak 131 dB 135 dB 135 dB 131 dB 134 dB 134 dB 131 dB 133 dB 133 dB
Transducers
Low Frequency 1 × Bose LF14 neodymium 14-inch woofer (4-inch voice coil)
High Frequency 6 × Bose EMB2S titanium-diaphragm, neodymium compression drivers (2-inch voice coil)
Nominal Impedance Passive: 8 Ω / Bi-amp: 8 Ω + 8 Ω
Physical
Enclosure Material Exterior-grade birch plywood
Finish Two-part polyurethane coating, black
Grille Powder-coated perforated stainless steel, acoustic foam, stainless steel mesh
Environmental Rated for direct-exposure outdoor installations (IEC 60529: IP55)
Connectors Barrier strips: passive in/through, bi-amp, and 70V/100V, with cover
Suspension/Mounting 8 × M12 threaded inserts (4 per side); 2 × M10 threaded inserts (1 per side); 2 × M6
threaded inserts (1 per side); 1 M10 threaded insert, rear safety connection
Dimensions (H × W × D) – millimeters 409 × 783 420
Dimensions (H × W × D) – inches 16.1 × 30.8 × 16.5
Net Weight 36.3 kg (80 lbs)
Shipping Weight 43.5 kg (96 lbs)
Accessories U-bracket, array suspension kits, waveguide kits
Footnotes
1. Frequency response and range measured on-axis in anechoic environment with recommended bandpass and EQ.
2. Bose extended-lifecycle test using pink noise filtered to meet IEC268-5, 6-dB crest factor, 500-hour duration.
3. AES standard 2-hour duration with IEC system noise.
4. Sensitivity measured in anechoic environment with recommended bandpass and EQ.
5. Maximum SPL calculated using sensitivity and power ratings, exclusive of power compression.
