English • 17Installation Guide • ArenaMatch Utility
PRO.BOSE.COM
Installation
Attaching the Input Panel Cover
ArenaMatch Utility loudspeakers are shipped with the rear input panel cover not installed. Once you've made
input wiring connections, secure the cover over the input panel with the included M4 screws.
Loudspeaker Pitch Angles
The maximum pitch angles for AMU loudspeakers when horizontally mounted with the included U-bracket are
as follows:
Wall-mounted Ceiling-mounted
AMU105 –110° –110°
AMU108 –110° –110°
AMU206 –110° –110°
AMU208 –110° –110°
