Bose AV28 User Manual

39
Main Part List
Refer to Figure 3
Item
Number
Description Part Number Qty Note
1 DVD-ROM, DV-505SFV7 V1.014R7622 301728-005 or 301728-006 3
2 MAIN PCB ASSEMBLY, SLAB 276328 1 1,2,4
3 TUNER , US, PCB ASSEMBLY 260322-1 1 1, 2, 4
4 KEYPAD, PCB ASSEMBLY 254141 1 1, 2
5 PAD, HEAT TRANSFER, 14.6mm, NOTCH 262872-001 1
6 MODULE, VFD 256149-001 1
7 TOP COVER ASSEMBLY 266280-001 1
8 DOOR ASSEMBLY 264353-002 1
9 BASE, EMI 256153-001 1
10, 12 END CAP ASSY, LEFT 266437-001 1
11, 13 END CAP ASSY, RIGHT 266438-001 1
14 LENS, IR 256158-001 1
15 BRACKET, DVD 256729 1
16 PAD, SWITCH, ELASTOMERIC 256745-001 1
17 CABLE, DVD, PWR, 4 POS, 240mm 304996-265 1
18 CABLE, SIGNAL, IDE, 40 PIN, 300mm 256145-40300 1
19 CABLE, FFC, 26 POS, 130mm 256147-30130 1
20 FOOT, RUBBER 188462-001 6
21 BRACKET, SUPPORT, TUNER PCB 256748-001 1
22 SCREW, M3-0.5, SYM, PAN, XREC 256752-005 4
23 CLIP, SPACER, DAMPER 260386 1
24 PLATE, STRIKER 256756-001 1
25 SPRING, DOOR 256757-001 1
26 MAGNET, DOOR 258357 1
27 GEAR, DAMPER, UP RIGHT, TYPE-F 256797-04 1
28 SCREW, TAP, 8-11X.625, PAN, XRC/SQ 193637-10 6
29 GASKET, EMI 272391-085 1
30 GASKET, EMI 256160-002 1
31 GASKET, EMI, STRAIGHT 260383-003 1
32 GASKET, EMI 256160-004 1
33 CABLE, 10 POS, SPLIT 256734-001 1
34 CABLE, HEADPHONE, 4POS, 70mm 256775-04070 1
35 SCREW, TAPP, 6-13x.5, PAN, XREC/SQ 172783-08 1
36 GASKET, EMI 256160-005 1
37 GASKET, EMI, STRAIGHT 260383-001 1
38 CLIP, GROUNDING 258488 1
39 FACE PLATE, TRAY, DVD 277049-201 1
40 GASKET, EMI 262876-100 1
41 BEZEL 256156-201 1
42 LENS, VFD DISPLAY 256157-001 1
- SPACER ARM 263181 1
- SHIM, HEADPHONE JACK 262878 1
