8 • English DesignMax DM6SE • Installation Guide
PRO.BOSE.COM
Installation
Removing the Grille
There are two small openings on either side of the grille (1). Along the side
of the loudspeaker with the bracket slots, insert a small, flat tool into the
grille openings to disengage the release tabs. Pull the grille away from the
loudspeaker.
q q
Safety and Regulatory Compliance
The Bose DesignMax DM6SE loudspeaker has passed testing and complies with the following specifications and uses:
Listed to ANSI/UL 1480A-2016, Speakers for Commercial & Safety Professional Use
General-Purpose Use - UL Category UEAY, File Number S 5591 Control Number 3N89
The DesignMax DM6SE is suitable for use outdoors in wet locations
Suitable for installation using Class 1, Class 2, Class 3 wiring methods in accordance with NFPA 70, National Electrical Code,
2017, Article 640
The DesignMax DM6SE loudspeaker has been designed to the requirements defined in the following European regulatory specification
for combination systems:
Tested to IEC60268-5, 2007
Adjusting the Logo
You can rotate the Bose logo to align with your loudspeaker
orientation. With one hand, press the button on the back of
the grille. Rotate the logo with the other hand. The logo can be
rotated clockwise or counterclockwise.
Note: Do not pinch the button inward unless you intend to
remove the logo.
Attaching the Grille
Place the grille over the front of the loudspeaker and push it
firmly until it snaps into place.
