Bose F1 812P User Manual

8
Figure 2. F1 Model 812P Loudspeaker - Side Grilles and Mount Interface
MAIN PART LIST
F1 Model 812P Loudspeaker (refer to Figure 2)
Item
Number
Description Part Number Qty. Note
11 SCREW, M4x25, PH, BLK
(FOOT, WOOFER, TWID ARRAY PLASTIC)
721717-001S 16
44 SCREW, M4x20, FH, BLK - 6
45 GASKET, STAND MOUNT INTERFACE, SVCE 628346-001S 1
46 POLE MOUNT INTERFACE, PASSIVE, MH, SVCE 757437-011S 1
47 FOOT, FRONT LEFT, MH, SERV 625288-011S 1
48 FOOT, FRONT RIGHT, MH, SERV 625288-012S 1
50 KIT, LOGO, ASSY, MH, BLK, SVCE 720197-011S 1
51 GRILLE, ARRAY, CENTER , SERV
(NO LOGO, ORDER ITEM 50 IF NEEDED)
625267-011S 1
52 GRILLE, SIDE, MH, SERV 625268-011S 2
