Bose FreeSpace 3 Service Manual

10
CROSSOVER ELECTRICAL PART LIST
Resistors
Capacitors
Inductors
Miscellaneous
Reference
Designator
Description Part Number Note
R11 5.1 OHM, WW, 5W 132105-5R1 4
R21 5.1 OHM, WW, 5W 132105-5R1 4
Reference
Designator
Description Part Number Note
C10 100uF, EL, 85ºc, 50V, 20% 289958-101 4
C20 100uF, EL, 85ºc, 50V, 20% 289958-101 4
C11 10uF, EL, BP, 85ºc, 50V, 20% 290391-100 4
C21 10uF, EL, BP, 85ºc, 50V, 20% 290391-100 4
Reference
Designator
Description Part Number Note
L11 350 uH 292703-001 4
L21 350 uH 292703-001 4
Reference
Designator
Description Part Number Note
PTC11 POLYSWITCH, 60V, 4mm 190348-110K 4
PTC21 POLYSWITCH, 60V, 4mm 190348-110K 4

Bose FreeSpace 3 Specifications

General

Certification	CE
Product color	White
Housing material	Polystyrene (PS)
Recommended usage	-
Suitable for outdoor use	No
Driver diameter	64 mm
Number of drivers	1
Speaker placement	Tabletop/bookshelf, Wall-mountable
Audio output channels	2.0 channels
Impedance	5 Ω
Sensitivity	82 dB
Frequency range	50 - 16000 Hz
RMS rated power	- W
Package weight	1800 g
Transformer taps	25, 50, 100, 200 W
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	102 mm
Width	77 mm
Weight	800 g
Depth (with stand)	149 mm
