Setting Up
Miniature switches
Battery compartment cover
3 AA batteries
Setting radio channel spacing for dual voltage and 120V systems
Dual voltage music centers (which include both 120V and 230V power packs) can be set for
two types of AM and FM channel spacing.
• 10 kHz for AM and 200 kHz for FM (common to North America)
• 9 kHz for AM and 50 kHz for FM (common to Europe)
Your dual voltage music center is preset for North American spacing. Select the channel
spacing most appropriate for your area.
To change between North American and European channel spacing:
1. Turn the music center off.
2. Press and hold the ERASE key (on the music center control panel) for three seconds. The
display flashes PROGRAM and indicates US for North American spacing or Euro for
European spacing.
3. While holding the ERASE key, press SOURCE SELECT (on the music center control
panel). The display flashes PROGRAM and the setting changes from US to Euro. While
holding ERASE, press SOURCE SELECT again to change from Euro to US.
Installing the batteries in the remote control
1. Slide open the battery compartment on the back of the remote (Figure 15).
2. Insert 3 AA or IEC-R6 1.5V batteries, or the equivalent, as shown. Match the + and –
symbols on the batteries with the + and – markings inside the compartment.
3. Slide the battery compartment cover back into place.
Replace the batteries when the remote control stops operating or its range seems reduced.
Alkaline batteries are recommended.
Note:
Do not change the settings of the factory-preset miniature switches. See “Changing
the house code settings” on page 32 for information on how to prevent conflicts with other
Lifestyle
®
music systems.
Figure 15
Installing the remote control
batteries
