Bose SoundTouch Portable Series II User Manual

English - 19
7. Remove the screws that secure the battery pack.
8. Remove the old battery and gently slide the new battery into the compartment.
9. Replace and tighten the screws on the battery pack.
Note: Tighten the left screw first to ensure the battery's pins align with the
connectors inside the compartment.
10. Align the cover's hooks to the tabs and press the cover down.
11. Replace and tighten the screws on the cover.
12. Connect the system to AC power and fully charge the battery (about three
hours).
Note: The battery status icon on the display indicates charging status. To
check the battery's charge level, press
on the button pad for 2
seconds.
20 V
20V
Using the System

Bose SoundTouch Portable Series II Specifications

General

Control type	Buttons
Volume control	Digital
Remotely operated	Yes
Supported radio bands	Not supported
Built-in storage media	No
Audio formats supported	AAC, MP3, WMA
Internet radio services supported	iHeartRadio, Pandora, Spotify
Network streaming services supported	Pandora
Display type	OLED
Product color	Black, White
RMS rated power	- W
Number of drivers	-
Audio output channels	2.0 channels
Wi-Fi standards	802.11b, 802.11g
Cables included	AC, USB

Weight and Dimensions

Depth	64 mm
Width	249 mm
Height	147 mm
Weight	1400 g
