Braun Thermoscan IRT 4000 series
Indications for use:
IRT 4000 series
The Braun ThermoScan IRT 4000 series infrared ear thermometers are indicated for the
intermittent measurement and monitoring of human body temperature by consumers in a
home use environment.
Product specifications
Model No: IRT 4020, IRT 4520
Accessories: Protective cap (LF20)
Manufactured by: Key Tronic Corporation.
Magneto # 7824, Parque Ind. Gema. Plant 1,
Juarez, Chihuahus, Mexico
Manufactured for: Kaz Europe S.A.,
Place Chauderon 18, CH-1003 Lausanne, Switzerland
Physical size and weight
Instrument
The physical size of the instrument shall be approx. 152mm, by 44mm, by 33mm. The
weight shall be approx. 100g, without the batteries.
Cap
The physical size of the cap shall be approx. 35mm, by 35mm, by 20mm. The weight shall
be approx. 15g. The cap shall protect the probe against pollution. It shall not cover the LC
display.
Instrument cover
The physical size of the instrument cover shall be approx. 160mm by 75mm by 38mm. The
weight shall be approx. 30g.
Range definition/ Feature matrix
Product
ThermoScan ThermoScan
IRT 4520 IRT 4020
Temperature measurement within
seconds ■ ■
Temperature range °C 34-42.2 34-42.2
Temperature range °F 93.2-108.0 93.2-108.0
ExacTemp technology ■ ■
Feedback system ■ ■
Ready beep ■ ■
Small, soft tip ■ ■
Flexible tip ■ ■
Memory storage capacity 8 1
Auto-off after 60 sec. 60 sec.
Easy-to-read LCD display ■ ■
Lens lter detector ■ ■
Lens lter ejector ■ ■
Protective case with lens lter
storage ■
Protective cap ■
Batteries included ■ ■
21 lens lter included ■ ■
Colour Blue Green
Feature
IRT 4020 IRT 4520
(Mass) (6 023) (Pharmacy) (6 022)
Sensor system Unique ExacTemp sensor technology
Site offsets Ear mode
Patient temp. range 34°C..42.2°C
Ambient temp. range 10°C..40°C
Operating lifetime 5 years/ 10 000 readings
Battery type 2* AA (LR6)
Battery lifetime at
normal ambient temp. 1000 readings and 5 years shelf life
Probe protection and
thermometer storage
Simple cap for probe
protection only
IRT instrument cover to hold
thermometer and LF 20
Battery charging N/A
Charging time N/A

Braun ThermoScan IRT 4520 Specifications

General

Measurement Method	Infrared
Display	LCD
Automatic Shut-off	Yes
Type	Ear thermometer
Fever Alarm	Yes
Age Precision Technology	Yes
Warranty	2 years
Battery Type	2 x AA batteries
Measurement Range	34 - 42.2°C (93.2 - 108°F)
Display Resolution	0.1°C/°F
Age Range	All ages
Measurement Time	Few seconds
Accuracy	±0.2°C (±0.4°F)
