Switch and Sensor Locations
Barrier Down
Limit Switch
73950RNA
Lift Out Cam
73775
Pressure
Transducer
30426
Full Out Cam
75776CN
Lift Out
Limit Switch
73950A
Full Out
Limit Switch
73950A
Switch 1
Limit Switch
73950A
Switch 0
Limit Switch
73950A
Switch 0 Cam
73712
Switch 1 Cam
73712
Below Stow
Limit Switch
73950A
Floor Level
Limit Switch
73950A
Floor Level
Cam
73712
Below Stow
Cam
73712
Handrail Belt
Assembly
34031A
