14 BRIGGSandSTRATTON.com.au
Connecting Electrical Loads
1. Make sure the green output indicator light comes
on (it may take up to three seconds).
2. Let engine stabilize and warm up for a few
minutes after starting.
3. Plug in and turn on the desired 230 Volt AC,
NOTICE
• DO NOT connect 115 Volt loads to the 230 Volt
receptacles.
• DO NOT connect 3-phase loads to the generator.
Generator Capacity.
NOTICE
Exceeding generators wattage/amperage
capacity could damage generator and/or electrical
devices connected to it.
• DO NOT exceed the generator’s wattage/amperage
capacity. See Generator Capacity.
• Start generator and let engine stabilize before connecting
electrical loads.
• Connect electrical loads in OFF position, then turn ON for
operation.
• Turn electrical loads OFF and disconnect from generator
before stopping generator.
Parallel Operation
Two Briggs & Stratton inverter generators can be run
in parallel with a Briggs & Stratton parallel operation kit
(optional equipment) for a total output of power of up to
4,800 watts (4.8 kW).
Models Maximum Output
P2200 & P2200 3000 Watts
P2200 & P3000 3000 Watts
P3000 & P3000 4800 Watts
NOTICE Total electrical load connected to the
parallel kit must not exceed 4,800 watts (4.8 kW).
See the parallel operation kits instruction sheet for
detailed instructions on installation and operation of the
connected generators.
NOTICE
• Turn electrical loads OFF and disconnect from
both generators.
• The QPT switch must be in the same position on
both generators.
• Connect the power cables to both generators
before starting the engines. See instruction sheet
supplied with parallel kit.
• Start engine on one of the inverter generators
according to Starting the Engine.
• Once the green LED output indicator light on the
first generators is steady, start second generator.
• Connect and turn on electrical loads to the parallel
panel receptacles.
• DO NOT disconnect power cables after engines
have been started.
• Shut down engines as described in Stopping the
Engine.
Stopping the Engine
1. Turn OFF and unplug all electrical loads from
generator panel receptacles. NEVER start or stop
engine with electrical devices plugged in and
turned ON.
2. Let engine run at no-load for several minutes
to stabilize internal temperatures of engine and
generator.
3. Turn engine switch to the OFF (0) position.
This feature is designed to greatly improve fuel
economy. When this switch is turned ON, the
engine speed will increase as electrical loads are
connected, and decreased as electrical loads are
removed.
With the switch off, the engine will run at a higher
speed.
NOTICE Always have the switch OFF when using the
DC receptacle.
WARNING Fuel and its vapors are extremely
flammable and explosive which could
cause burns, fire or explosion
resulting in death or serious injury.
• DO NOT stop engine by moving choke lever to
( ) position.
