Brother 2340CV User Manual

8
II. Preparation before threading
4
1
2
3
Raise the telescoping thread tree to its highest position.
Make sure that the thread holders are in alignment above
the spool pins as illustrated left.
1 Thread holder on thread tree
2 Spool pin
3 Spool cushion
4 Correct position
Thread spool
The procedure for placing the spool of thread on the spool pin differs according to the shape of the spool.
3
If you are sewing with loosely
spun nylon thread, we recom-
mend that you cover the spool
with the net supplied to prevent
the thread from slipping off the
spool.
Adapt the net to the shape of the
spool.
1 Spool support
2 Spool cushion
3 Net
1 Spool support
2 Spool mat
3 Spool cap
Type A Type B
Thread tree
1
2
1
2
3
(1)
(2)
(1)Turn off the main power switch for safety.
Needle position
(2)Set the needle bar in its highest position by turning the
handwheel toward you.
Turn the handwheel to find the easiest position for
threading.

Brother 2340CV Specifications

General

AC input voltage	110 V
Power supply type	Electric
Free arm	No
Control type	Rotary
Sewing speed	1100
Product color	White
Stitch length	Variable
Built-in light	Yes
Buttonhole type	-
Sewing machine functions	Sewing
Number of stitch patterns	5
Sewing machine accessories included	Cover

Weight and Dimensions

Depth	340.3 mm
Width	279.4 mm
Height	299.7 mm
Weight	6803 g
