Loading documents and paper
11
2
How to load envelopes and postcards 2
a Before loading, press the corners and
sides of envelopes or post cards to
make them as flat as possible.
Note
If envelopes or post cards are ‘double-
feeding’, put one envelope in the paper
tray at a time.
b Put envelopes or post cards into the
paper tray with the address side down
and the leading edge (top of the
envelopes) in first. With both hands,
gently press and slide the paper side
guides (1) and paper length guide (2) to
fit the size of the envelopes or post cards.
If you have problems when printing on
envelopes, try the following suggestions:
2
a Make sure the flap is either to the side of
the envelope or to the back edge of the
envelope when printing.
b Adjust the size and margin in your
application.
Removing small printouts
from the machine 2
When the machine ejects small paper onto
the output paper tray you may not be able to
reach it. Make sure printing has finished, and
then pull the tray completely out of the
machine.
2
1

Brother DCP-145C Specifications

General

Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Print speed (black, normal quality, A4/US Letter)	27 ppm
Print speed (color, normal quality, A4/US Letter)	22 ppm
Digital sender	No
Number of print cartridges	4
Scan to	E-mail
Grayscale levels	256
Image formats supported	PNG
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	1200 x 1200 DPI
Copy speed (black, normal quality, A4)	5 cpm
Dimensions (WxDxH)	390 x 365 x 150 mm
All-in-one functions	Copy, Scan
Standard input trays	100
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000SP4, Vista/XP (32/64 bit). Mac 10.2.4, Linux
Display	LCD
Market positioning	Home & office
Sound pressure level (printing)	50 dB
Maximum print size	216 x 356 mm
Media weight (tray 1)	64 - 220 gsm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Borderless printing media sizes	A4, A6
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Bundled software	Brother MFL-Pro Suite, Windows: Control Centre 3, Scan Soft Paper Port SE11, MAC: Control Centre 2, New Soft Presto, Page Manager 7
Power consumption (off)	2.5 W
Power consumption (standby)	3.5 W
Power consumption (average operating)	15 W
Package weight	8100 g
