Cambridge Audio Azur 340A User Manual

14 azur integrated amplifier
There is no power
Ensure the AC power cord is connected securely
Ensure the plug is fully inserted into the wall socket and is switched on
Check fuse in the mains plug or adaptor
There is no sound
Make sure the unit is switched on
Check that source component is properly connected
Check that 'TAPE MON' is not switched on (unless tape input is required)
Check that your speakers are properly connected
If using Speaker B terminals check they are switched on
If channel LED is flashing turn mute off
There is no sound on one channel
Ensure that balance control is in the correct position
Check speaker connections
Check interconnects
There is a loud buzz or hum
Check turntable or tone arm for ground and connection lead fault
Ensure no interconnects are loose or defective
Ensure that your tape deck/turntable is not too close to the amplifier
Unable to make or play tape recordings
Check that TAPE MON and TAPE OUT have been connected correctly
There is weak bass or diffused stereo imaging
Ensure that speakers are not wired out of phase
Protection LED flashing
Please see section on protection system (page 13)
TROUBLESHOOTING
Power Output
Max Power Consumption
Total Harmonic Distortion
Frequency Response
(-11dB)
S to N Ratio
(unweighted)
Slew Rate
(into 8ΩΩ)
Dimensions
(HxWxD)
mm
inches
Weight
kg
Lbs
SPECIFICATIONS
340A
40W (into 8Ω)
50W (into 4Ω)
345W
1kHz < 0.01%
20kHz < 0.09%
5Hz - 50kHz
92dB
20V/uS
70 x 430 x 310
2.8 x 16.9 x 12.2
6.2
13.6
AP171421 azur 340A English.Chinese User’s Manual Contents - print pantone 2768.qxd 17/01/2005 10:00 Page 13

Cambridge Audio Azur 340A Specifications

General

Power Output	40W per channel (8 Ohms)
Signal to Noise Ratio	>92dB
Input Impedance	47k Ohms
Damping Factor	50
Total Harmonic Distortion	<0.02%
