3 Shooting Video Snapshots
168
Options in Steps 4 and 5
[Playback video snapshot] Operations
*With [Skip backward] and [Skip forward], the skipping duration will correspond to the
number of seconds set under [Video snapshot] (approx. 2 sec., 4 sec., or 8 sec.).
Function Description
J Save as album
(Step 4)
The movie clip will be saved as the video snapshot
album’s first video snapshot.
J Save as album
(Step 5)
The video snapshot just recorded will be added to
the album recorded immediately before.
W Save as a new album
(Step 5)
A new video snapshot album is created and the
movie clip is saved as the first video snapshot. Select
[
OK
] on the confirmation dialog. The new album will
be a different file from the previously recorded album.
1
Playback video snapshot
(Steps 4 and 5)
The video snapshot just recorded will be played. For
playback operations, see the table below.
r Do not save to album
(Step 4)
r
Delete without
saving to album
(Step 5)
The video snapshot you just recorded will be erased
instead of being saved to the album. Select [OK] on
the confirmation dialog.
Function Playback Description
2 Exit The previous screen will reappear.
7 Play
By pressing <0>, you can play or pause the just-
recorded video snapshot.
5 First frame Displays the first scene of the album’s first video snapshot.
Skip backward*
Each time you press <0>, the video snapshot skips back
by a few seconds.
3 Previous frame
Each time you press <0>, the previous frame is
displayed. If you hold down <0>, it will rewind the movie.
6 Next frame
Each time you press <
0
>, the movie will play frame-by-
frame. If you hold down <
0
>, it will fast forward the movie.
Skip forward*
Each time you press <0>, the video snapshot skips
forward by a few seconds.
4 Last frame Displays the last scene of the album’s last video snapshot.
Playback position
mm’ ss” Playback time (minutes:seconds)
9 Volume
You can adjust the built-in speaker’s (p.214) volume by
turning the <6> dial.
COPY

Table of Contents

Other manuals for Canon EOS Rebel T5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon EOS Rebel T5 and is the answer not in the manual?

Canon EOS Rebel T5 Specifications

General IconGeneral
Megapixel18 MP
Camera typeSLR Camera Kit
Sensor typeCMOS
Sensor formatAdvanced Photo System type-C (APS-C)
Image stabilizerNo
Total megapixels18.7 MP
Image formats supportedJPG, RAW
Supported aspect ratios3:2
Maximum image resolution5184 x 3456 pixels
Image sensor size (W x H)22.3 x 14.9 mm
Still image resolution(s)3456 x 2304 2592 x 1728 1920 x 1280 720 x 480
Lens typeStandard zoom
Filter size58 mm
Focal length range18 - 55 mm
Lens mount interfaceCanon EF, Canon EF-S
Maximum aperture number5.6
Minimum aperture number3.5
Lens structure (elements/groups)11/9
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto focusing (AF) modesAI Focus, One Shot Focus, Servo Auto Focus
Closest focusing distance0.25 m
Auto Focus (AF) points selectionAuto, Manual
Light meteringCentre-weighted, Evaluative (Multi-pattern), Partial
ISO sensitivity100, 400, 800, 1600, 3200, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction±5EV (1/2; 1/3 EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed30 s
Flash modesAuto, Flash off, Red-eye reduction
Flash guide number9.2 m
Flash recharging time2 s
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Maximum video resolution1920 x 1080 pixels
Resolution at capture speed640x480@25fps, 640x480@30fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Memory slots1
Compatible memory cardsEye-Fi, SD, SDHC, SDXC
Touchscreen-
Field of view100 %
Display diagonal3 \
Display aspect ratio4:3
Display resolution (numeric)460000 pixels
Magnification0.8 x
Viewfinder typeOptical
USB version2.0
HDMI connector typeMini
Scene modesClose-up (macro), Night portrait, Portrait, Sports, Landscape (scenery)
Photo effectsBlack&White, Neutral
Start-up time100 ms
White balanceAuto
Camera playbackSingle image, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3
Power source typeBattery
Battery typeLP-E10
Battery life (CIPA standard)600 shots
Product colorBlack
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 85 %
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth77.9 mm
Width129.6 mm
Height99.7 mm
Weight435 g
