CONDENSER ONLY RATINGS*
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ACB724A**31
30
( --- 1.11)
TCG 28.00 25.00 21.90 18.90 16.00 13.30 10.70 8.50
SDT 71.60 81.50 91.40 101.20 111.00 120.80 130.80 140.90
KW 1.20 1.30 1.40 1.51 1.63 1.76 1.92 2.11
35
(1.67)
TCG 31.20 27.70 24.30 21.00 17.80 14.80 12.10 9.60
SDT 73.20 83.00 92.80 102.60 112.40 122.20 132.10 142.10
KW 1.23 1.33 1.43 1.53 1.65 1.79 1.95 2.14
40
(4.44)
TCG 34.60 30.70 26.90 23.20 19.80 16.50 13.50 10.70
SDT 74.80 84.60 94.40 104.10 113.90 123.50 133.40 143.30
KW 1.25 1.35 1.45 1.56 1.68 1.82 1.98 2.17
45
(7.22)
TCG 38.20 33.90 29.70 25.70 21.90 18.30 15.00 12.00
SDT 76.60 86.30 96.00 105.70 115.20 124.90 134.70 144.60
KW 1.28 1.38 1.48 1.58 1.70 1.84 2.01 2.20
50
(10.0)
TCG 42.00 37.30 32.60 28.30 24.10 20.20 16.60 13.40
SDT 78.40 88.00 97.60 107.10 116.70 126.30 136.00 145.90
KW 1.31 1.40 1.50 1.60 1.72 1.87 2.03 2.23
55
(12.78)
TCG 46.10 40.90 35.80 31.00 26.50 22.30 18.40 14.80
SDT 80.20 89.70 99.20 108.60 118.10 127.70 137.40 147.10
KW 1.34 1.43 1.52 1.63 1.75 1.89 2.06 2.26
60
(15.56)
TCG 50.50 44.70 39.20 33.90 29.00 24.40 20.20 16.30
SDT 82.00 91.40 100.80 110.20 119.70 129.20 138.80 148.40
KW 1.37 1.45 1.54 1.65 1.77 1.92 2.09 2.28
24ACB724A**31
30
( --- 1.11)
TCG 13.50 13.60 13.30 12.80 12.20 11.30 10.40 9.40
SDT 66.80 76.80 86.70 96.50 106.30 116.00 125.70 135.70
KW 0.77 0.89 1.03 1.18 1.35 1.53 1.74 1.96
35
(1.67)
TCG 15.20 15.20 14.90 14.40 13.70 12.90 11.90 10.90
SDT 68.00 78.00 87.90 97.70 107.40 117.10 126.90 136.90
KW 0.77 0.89 1.02 1.17 1.34 1.53 1.74 1.98
40
(4.44)
TCG 16.90 16.90 16.60 16.00 15.30 14.50 13.50 12.50
SDT 69.30 79.30 89.00 98.80 108.50 118.20 128.10 138.10
KW 0.76 0.88 1.01 1.17 1.34 1.53 1.75 1.99
45
(7.22)
TCG 18.80 18.70 18.30 17.80 17.00 16.20 15.20 14.10
SDT 70.60 80.50 90.30 100.00 109.70 119.40 129.20 139.20
KW 0.75 0.87 1.00 1.16 1.33 1.53 1.76 2.01
50
(10.0)
TCG 20.80 20.60 20.20 19.60 18.90 18.00 17.00 15.90
SDT 72.00 81.80 91.50 101.20 110.80 120.50 130.40 140.30
KW 0.74 0.86 0.99 1.15 1.33 1.53 1.76 2.02
55
(12.78)
TCG 22.90 22.70 22.20 21.60 20.80 19.90 18.80 17.80
SDT 73.40 83.20 92.80 102.40 112.10 121.70 131.50 141.40
KW 0.73 0.84 0.98 1.14 1.32 1.53 1.77 2.03
60
(15.56)
TCG 25.10 24.80 24.30 23.70 22.80 21.90 20.80 19.70
SDT 74.90 84.60 94.10 103.70 113.30 122.90 132.60 142.40
KW 0.72 0.83 0.97 1.13 1.32 1.53 1.77 2.04
24ACB736A**31 --- High
30
( --- 1.11)
TCG 34.80 32.30 29.80 27.40 25.00 22.60 20.10 17.60
SDT 71.10 80.60 90.10 99.60 109.10 118.50 127.80 137.20
KW 1.72 1.87 2.04 2.25 2.47 2.72 3.00 3.29
35
(1.67)
TCG 38.50 35.70 33.10 30.40 27.80 25.10 22.40 19.60
SDT 72.60 82.00 91.50 100.90 110.30 119.70 128.90 138.20
KW 1.76 1.91 2.08 2.28 2.50 2.76 3.03 3.33
40
(4.44)
TCG 42.40 39.40 36.50 33.60 30.70 27.80 24.80 21.80
SDT 74.20 83.60 93.00 102.40 111.70 120.90 130.10 139.20
KW 1.81 1.95 2.11 2.31 2.53 2.79 3.06 3.37
45
(7.22)
TCG 46.50 43.30 40.20 37.00 33.90 30.70 27.50 24.20
SDT 75.90 85.20 94.50 103.80 113.00 122.20 131.30 140.30
KW 1.87 1.99 2.15 2.34 2.57 2.82 3.10 3.40
50
(10.0)
TCG 50.90 47.50 44.00 40.60 37.20 33.80 30.30 26.70
SDT 77.60 86.80 96.10 105.30 114.40 123.50 132.50 141.40
KW 1.92 2.04 2.19 2.38 2.60 2.85 3.13 3.44
55
(12.78)
TCG 55.50 51.80 48.10 44.50 40.80 37.00 33.20 29.40
SDT 79.40 88.50 97.70 106.80 115.90 124.90 133.80 142.60
KW 1.99 2.09 2.24 2.42 2.64 2.89 3.17 3.47
60
(15.56)
TCG 60.40 56.40 52.50 48.50 44.50 40.40 36.40 32.30
SDT 81.20 90.20 99.30 108.40 117.40 126.30 135.00 143.80
KW 2.05 2.15 2.29 2.47 2.68 2.93 3.20 3.51
See notes on page 19
