Carrier 30AWH012H User Manual

1
30AWH
Air / Water Cycle Heat Pump
This air conditioner adopts the new HFC refrigerant t
(R410A) which does not destroy ozone layer.
R-410A refrigerant operates at 50%-70% higher pressures t
than R-22. Be sure that servicing equipment and
replacement components are designed to operate with
R-410A.
R-410A refrigerant cylinders have a dip tube which allows t
liquid to ow out with the cylinder in a vertical position
with the valve at the top.
R-410A systems should be charged with liquid t
refrigerant. Use a commercial type metering device in the
manifold hose in order to vaporize the liquid refrigerant
before it enters in the unit.
As for other HFC, R-410A refrigerant is only compatible t
with oils recommended by the compressor manufacturer.
A vacuum pump is not enough to remove moisture from t
oil.
Oils absorb moisture rapidly. Do not expose oil to t
atmosphere.
Never open system to atmosphere while it is under t
vacuum.
When the system must be opened for service, break t
vacuum with dry nitrogen.
Do not vent R-410A into the atmosphere.t
Use this unit only for factory approved applications.
The capacity and unit code are stated on the nameplate
data.
R-410A - General info
SITING THE UNIT
INSTALLATION
R-410A - General info .......................................................... 1
Safety procedures ................................................................ 2
Dimensions and clearances............................................... 4
Technical data ....................................................................... 4
Installation ............................................................................. 5
Water connections ............................................................... 6
Electrical connections ......................................................... 8
Connection of Auxiliary Accessories .............................. 9
System test ............................................................................. 12
Unit protection devices ...................................................... 15
Maintenace ............................................................................ 15
Contents Page
WATER CONNECTIONS
ELECTRICAL CONNECTIONS
CONTROL WIRING (Optional)
POWER WIRING
FILLING THE SYSTEM
FLUSHING WATER AND AIR
CHECKING FOR WATER LEAKS
CONFIGURING AND CHECKING THE SYSTEM
CAUTION:
t Do not leave system open to atmosphere any longer
than minimum required for installation.
t 0JMJOUIFDPNQSFTTPSJTFYUSFNFMZTVTDFQUJCMFUP
moisture absorption.
MODELS WITH HYDRONIC
MODULE
MODELS WITHOUT
HYDRONIC MODULE
30AWH004HB 30AWH004XB
30AWH006HB 30AWH006XB
30AWH008HB 30AWH008XB
30AWH012HB 30AWH012XB
30AWH015HB 30AWH015XB
English
