7 - PHYSICAL DATA 30GX
30GX 082 092 102 112 122 132 152 162 182 207 227 247 267 298 328 358
Net cooling capacity* kW 285 309 332 388 417 450 505 536 602 687 744 810 910 1003 1103 1207
Operating weight kg 3116 3157 3172 3515 3531 3633 3920 3936 4853 5540 5570 6134 6365 7354 7918 8124
Refrigerant charge HFC-134a
Circuit A/B kg 55/55 58/50 54/53 55/53 60/57 63/60 75/69 75/75 80/80 130/85 130/85 155/98 170/104 162/150 162/165 175/175
Oil Polyolester oil CARRIER SPEC: PP 47-32
Circuit A/B l 20/20 20/20 20/20 20/20 20/20 20/20 20/20 20/20 20/20 40/20 40/20 40/20 40/20 40/40 40/40 40/40
Compressors Hermetic twin-screw Power
3
Circ.A, nom. size per compressor** 46 46 56 56 66 66 80 80 80+ 66/56 80/66 80/80 80+/80+ 80/80 80/80 80+/80+
Circ.B, nom. size per compressor** 39 46 46 56 56 66 66 80 80+ 80 80 80 80+ 66/66 80/802 80+/80+
Control type PRO-DIALOG Plus control
Number of capacity steps 6666666668888 1010 10
Minimum capacity % 19 21 19 21 19 21 19 21 21 16 14 14 14 9 10 10
Evaporator Shell and tube type, with internally finned copper tubes
Net water volume l 65 73 73 87 87 101 91 91 109 140 140 165 181 203 229 229
Water connections Factory-supplied flat flange, to be welded on site
Inlet and outlet in. 4445555556666 8 8 8
Drain and vent (NPT) in. 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Maximum water-side operating pressure kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Condensers Copper tubes and aluminium fins
Fans Axial FLYING BIRD 2 fan with rotating shroud
Quantity 444666888101012121416 16
Speed r/s 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8
Total air flow l/s 21110 21110 21110 31660 31660 31660 42220 42220 42220 52770 52770 63330 63330 73880 84440 84440
* Standardised Eurovent conditions: evaporator entering/leaving water temperatures = 12°C/7°C, outside air temperature = 35°C
Net cooling capacity: Gross cooling capacity minus the water pump heat against the internal evaporator pressure drop.
** The compressor size corresponds to the nominal capacity in tons (1 ton = 3.517 kW).
8 - ELECTRICAL DATA 30GX
30GX 082 092 102 112 122 132 152 162 182 207 227 247 267 298 328 358
Power circuit
Nominal power supply V-ph-Hz 400-3-50
Voltage range V 360-440
Control circuit supply The control circuit is supplied via the factory-installed transformer
Nominal power input* kW 98 109 123 133 150 166 179 196 214 246 281 292 332 364 394 449
Nominal current drawn * A 180 200 223 256 273 290 326 352 388 449 492 528 582 642 704 776
Maximum power input** kW 127 141 154 175 191 207 234 253 286 319 355 380 429 462 506 572
Circuit A kW - - - - - - - - - 193 228 253 286 253 253 286
Circuit B kW - - - - - - - - - 127 127 127 143 209 253 286
Cosine phi, unit at full load 0.85 0.85 0.85 0.85 0.85 0.85 0.86 0.86 0.86 0.86 0.86 0.86 0.86 0.86 0.86 0.86
Maximum current drawn (Un - 10%)*** A 237 262 287 323 353 383 429 464 524 585 650 696 786 847 928 1048
Circuit A A - - - - - - - - - 353 418 464 524 464 464 524
Circuit B A - - - - - - - - - 232 232 232 262 383 464 524
Maximum current drawn (Un)*** A 217 240 263 297 324 351 394 426 480 537 596 639 721 777 852 961
Circuit A A - - - - - - - - - 324 383 426 480 426 426 480
Circuit B A - - - - - - - - - 213 213 213 240 351 426 480
Max. starting current, standard unit**** (Un) A 334 357 401 435 468 495 590 622 662 1338 1631 1674 1767 1812 1887 2008
Circuit A*** A - - - - - - - - - 1125 1418 1461 1527 1461 1461 1527
Circuit B*** A - - - - - - - - - 1248 1248 1248 1287 1152 1461 1527
Max. starting current/max. current draw ratio,
unit 1.54 1.49 1.53 1.47 1.44 1.41 1.50 1.46 1.38 2.49 2.74 2.62 2.45 2.33 2.22 2.09
Max. starting current/max. current draw ratio,
circuit A - - - - - - - - - 3.47 3.70 3.43 3.18 3.43 3.43 3.18
Max. starting current/max. current draw ratio,
circuit B - - - - - - - - - 5.86 5.86 5.86 5.36 3.28 3.43 3.18
Max. starting current - reduced current
start**** (Un) A std. std. std. std. std. std. std. std. std. 878 955 998 1102 1136 1211 1343
Circuit A A std. std. std. std. std. std. std. std. std. 665 742 785 862 785 785 862
Circuit B A std. std. std. std. std. std. std. std. std. 572 572 572 622 692 785 862
Max.starting current - red. current start/max.
current draw ratio, unit std. std. std. std. std. std. std. std. std. 1.64 1.60 1.56 1.53 1.46 1.42 1.40
Circuit A std. std. std. std. std. std. std. std. std. 2.05 1.94 1.84 1.79 1.84 1.84 1.79
Circuit B std. std. std. std. std. std. std. std. std. 2.69 2.69 2.69 2.39 1.97 1.84 1.79
Three-phase short-circuit holding current kA 25 25 25 25 25 25 25 25 25 N/A N/A N/A N/A N/A N/A N/A
Circuit A kA - - - - - - - - -. 25 25 25 25 25 25 25
Circuit B kA - - - - - - - - - 25 25 25 25 25 25 25
Customer standby capacity, unit or circuit A,
for evaporator water pump connections † kW 4445.55.55.57.57.57.57.5999151515
* Standard Eurovent conditions: Evaporator entering/leaving water temperature 12°C and 7°C. Outdoor air temperature 35°C.
** Power input, compressor and fan, at unit operating limits (evaporator water entering/leaving temperature = 15°C/10°C, outdoor air temperature = 46°C) and a nominal voltage of 400 V (data
given on the unit name plate).
*** Maximum unit operating current at maximum unit power input.
**** Maximum instantaneous starting current (maximum operating current of the smallest compressor(s) + fan current + locked rotor current or reduced starting current of the largest
compressor).
† Current and power inputs not included in the values above
N/A Not advailable
