Carrier 40RU User Manual

20
Table 4 – Electrical Data, Standard Motors
UNIT V --- P H --- H z
{
VOLTAGE
LIMITS
FAN MOTOR POWER SUPPLY
Hp (kW) FLA
Minimum
Circuit Amps
MOCP
40RUA*07
40RUQ
*07
208/230---1---60 187--- 253 1.3 (0.97) 7.6 9.5 15
208/230---3---60 187--- 253 2.4 (1.79) 5.8 7.3 15
4 6 0 --- 3 --- 6 0 414---506 2.4 (1.79) 2.6 3.3 15
5 7 5 --- 3 --- 6 0 518---632 1.0 (0.75) 1.4 1.7 15
40RUA*08
40RUQ
*08
40RUS
*08
208/230---1---60 187--- 253 2.4 (1.79) 11.0 13.8 20
208/230---3---60 187--- 253 2.4 (1.79) 5.8 7.3 15
4 6 0 --- 3 --- 6 0 414---506 2.4 (1.79) 2.6 3.3 15
5 7 5 --- 3 --- 6 0 518---632 2.0 (1.49) 2.4 8.0 15
40RUA*12
40RUQ
*12
40RUS
*12
208/230---3---60 187--- 253 2.4 (1.79) 5.8 7.5 15
4 6 0 --- 3 --- 6 0 414---506 2.4 (1.79) 2.6 3.3 15
5 7 5 --- 3 --- 6 0 518---632 2.0 (1.49) 2.4 3.0 15
40RUA*14
40RUS
*14
208/230---3---60 187--- 253 2.4 (1.79) 5.8 7.5 15
4 6 0 --- 3 --- 6 0 414---506 2.4 (1.79) 2.6 3.3 15
5 7 5 --- 3 --- 6 0 518---632 3.0 (2.24) 3.8 4.8 15
40RUA*16
40RUQ
*16
40RUS
*16
208/230---3---60 187--- 253 3.7 (2.76) 10.6 13.3 20
4 6 0 --- 3 --- 6 0 414---506 3.7 (2.76) 4.6 6.0 15
5 7 5 --- 3 --- 6 0 518---632 3.0 (2.24) 3.8 4.8 15
See Legend and Notes on page 21.
Table 5 – Electrical Data, Alternate Motors
UNIT V --- P H --- H z
{
VOLTAGE
LIMITS
FAN MOTOR POWER SUPPLY
Hp (kW) FLA
Minimum
Circuit Amps
MOCP
40RUA*07
40RUQ
*07
208/230---1---60 187--- 253 2.4 (1.79) 11.0/11.0 13.8/13.8 20
208/230---3---60 187--- 253 2.9 (2.16) 7.5 9.4 15
4 6 0 --- 3 --- 6 0 414---506 2.9 (2.16) 3.4 4.3 15
5 7 5 --- 3 --- 6 0 518---632 2.0 (1.49) 2.4 3.0 15
40RUA*08
40RUQ
*08
40RUS
*08
208/230---1---60 187--- 253 2.4 (1.79) 11.0 13.8 15
208/230---3---60 187--- 253 2.9 (2.16) 7.5/7.5 9.4/9.4 15
4 6 0 --- 3 --- 6 0 414---506 2.9 (2.16) 3.4 4.3 15
5 7 5 --- 3 --- 6 0 518---632 3.0 (2.24) 3.8 4.8 15
40RUA*12
40RUQ
*12
40RUS
*12
208/230---3---60 187--- 253 3.7 (2.76) 10.5/10.5 13.3/13.3 20
4 6 0 --- 3 --- 6 0 414---506 3.7 (2.76) 4.8 6.0 15
5 7 5 --- 3 --- 6 0 518---632 3.0 (2.24) 3.8 4.8 15
40RUA*14
40RUS
*14
208/230---3---60 187--- 253 3.7 (2.76) 10.2 12.7 20
4 6 0 --- 3 --- 6 0 414---506 3.7 (2.76) 4.8 6.0 15
5 7 5 --- 3 --- 6 0 518---632 5.0 (3.73) 5.1 6.4 15
40RUA*16
40RUQ
*16
40RUS
*16
208/230---3---60 187--- 253 5.0 (3.73) 14.6/12.8 18.3/16.0 30/25
4 6 0 --- 3 --- 6 0 414---506 5.0 (3.73) 6.4 8.0 15
5 7 5 --- 3 --- 6 0 518---632 5.0 (3.73) 5.1 6.4 15
See Legend and Notes on page 21.
Table 6 – Fan Contactor Coil Data
UNIT
40RU*
VOLTAGE
(vac)
MAXIMUM
HOLDING
VA
07, 08, 12, 14, 16 24 10
