42 VKG
GB - 4
Fix the remote control holder to the wall using the screw.
The remote controller operates with two 1.5 V non re-chargeable
batteries, type IEC LR03.
A fading display and reduced controller operating range indicate that
the batteries are exhausted.
How to insert batteries:
Open sliding cover.
Remove the cover by pressing on the plastic catch at the rear of
the controller.
Insert batteries paying attention to the correct polarity indicated in
the battery compartment; replace cover.
The maximum operating range for the remote controller is approx. 6 m.
No obstructions such as curtains or plants should be between
controller and unit. Direct sun on the unit receiver may interfere with
good signal reception. The controller must be directed toward the
unit receiver when pressing the buttons of the desired functions.
An acoustical acknowledgement sound (beep) will indicate that
signal has been received. If the signal has not been received,
renewed transmission is necessary by pressing any of the buttons
E, F, L or J situated under the sliding cover. After the acknowledgment
(beep), check the function displayed on the controller readout and
adjust or modify the selection made, if necessary. During signal
transmission symbol 1
will appear on the display (see next page).
When symbol 1
is lit it is not possible to send other signals.
A new signal can be sent only after symbol 1
has disappeared.
Infrared remote controller
Press
A. Display readout
B. On/Off button
C. Timer mode On/Off button
D. Mode selection button
E. Increase temperature button
F. Decrease temperature button
G. Timer program selection button
H. Set clock or timer hour button (Up)
I. Set clock or timer hour button (Down)
J. Fan speed selection button
K. Night mode button
L. Delivering louvre operating mode
M. Clock set button
BEEP
MODE
TEMPERA
