51
STANDARD MOTOR UNITS WITHOUT ELECTRICAL CONVENIENCE OUTLET
LEGEND
*Used to determine minimum disconnect per NEC.
†Fuse or HACR circuit breaker per NEC.
**Units have 2 condenser-fan motors.
NOTES:
1. In compliance with NEC requirements for multimotor and combina-
tion load equipment (refer to NEC Articles 430 and 440), the over-
current protective device for the unit shall be fuse or HACR
breaker. The UL, Canada units may be fuse or circuit breaker.
2. Electrical data based on 95 F ambient outdoor-air temperature
± 10% voltage.
UNIT
NOMINAL
VOLTAGE
(V-Ph-Hz)
VOLTAGE
RANGE
COMPRESSOR
(each)
OFM
(each)
IFM
COMBUSTION
FAN MOTOR
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE*
Min Max RLA LRA FLA FLA FLA MCA MOCP FLA LRA
48HJE/HJF004
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9 .57 25.6/25.6 35/35† 25/25 101/101
208/230-3-60 187 254 10.3 77.0 0.7 4.9 .57 18.5/18.5 25/25† 18/18 90/90
460-3-60 414 508 5.1 39.0 0.4 2.2 .30 9.0 15† 946
575-3-60 518 632 4.2 31.0 0.4 2.2 .30 7.3 15† 736
48HJD/HJE/HJF005
(4 Tons)
208/230-1-60 187 254 23.7 129.0 0.7 4.9 .57 35.2/35.2 45/45† 34/34 142/142
208/230-3-60 187 254 13.5 99.0 0.7 4.9 .57 22.5/22.5 30/30† 22/22 112/112
460-3-60 414 508 7.4 49.5 0.4 2.2 .30 11.9 15† 12 56
575-3-60 518 632 5.8 40.0 0.4 2.2 .30 9.3 15† 945
48HJD/HJE/HJF006
(5 Tons)
208/230-1-60 187 254 28.8 169.0 1.5 8.8 .57 46.3/46.3 60/60† 45/45 216/216
208/230-3-60 187 254 17.3 123.0 1.5 5.8 .57 28.9/28.9 35/35† 28/28 168/168
460-3-60 414 508 9.0 62.0 0.8 2.6 .30 14.7 20† 14 84
575-3-60 518 632 7.1 50.0 0.8 2.6 .30 11.6 15† 11 67
48HJD/HJE/HJF007
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 5.8 .57 32.8/32.8 40/40† 32/32 200/200
460-3-60 414 508 9.6 70.0 0.6 2.6 .30 15.2 20† 15 92
575-3-60 518 632 7.7 56.0 0.6 2.6 .30 12.2 15† 13 78
48HJD/HJE/HJF008
(7
1
/
2
Tons)**
208/230-3-60 187 254 12.4 88.0 1.4 7.5 .57 38.2/38.2 45/45† 40/40 242/242
460-3-60 414 508 6.4 44.0 0.7 3.4 .30 19.2 25† 20 121
575-3-60 518 632 4.8 34.0 0.7 3.4 .30 14.6 20† 16 95
48HJD/HJE/HJF009
(8
1
/
2
Tons)**
208/230-3-60 187 254 15.0 99.0 1.4 7.5 .57 44.1/44.1 50/50† 46/46 264/264
460-3-60 414 508 8.2 49.5 0.7 3.4 .30 23.3 30† 24 132
575-3-60 518 632 5.8 40.0 0.7 3.4 .30 16.9 20† 18 107
48HJD/HJE/HJF012
(10 Tons)**
208/230-3-60 187 254 17.3 123.0 1.4 10.6 .57 52.3/52.3 60/60† 55/55 337/337
460-3-60 414 508 9.0 62.0 0.7 4.8 .30 26.5 35† 26 171
575-3-60 518 632 7.1 50.0 0.7 4.8 .30 20.9 25† 22 136
48HJD/HJE014
(12
1
/
2
Tons)**
208/230-3-60 187 254 19.0 156.0 1.4 15.0 .57 60.6/60.6 70/70† 64/64 426/426
460-3-60 414 508 9.0 70.0 0.7 7.4 .30 29.1 30† 31 197
575-3-60 518 632 7.4 54.0 0.7 7.4 .30 23.7 30† 25 154
FLA —
Full Load Amps
HACR —
Heating, Air Conditioning and Refrigeration
IFM —
Indoor (Evaporator) Fan Motor
LRA —
Locked Rotor Amps
MCA —
Minimum Circuit Amps
MOCP —
Maximum Overcurrent Protection
NEC —
National Electrical Code
OFM —
Outdoor (Condenser) Fan Motor
RLA —
Rated Load Amps
UL —
Underwriters’ Laboratories
Electrical data
