Fig. 44—Sidewall Termination of 12 in. or Less

(Dimension "A" is Touching or 2-In.

Maximum Separation)

A96129

COMBUSTION AIR

VENT

Fig. 42—Concentric Vent and Combustion-Air

Roof Termination

(Dimension "A" is Touching or 2-In. Maximum Sepa-

ration)

A93056

COMBUSTION

AIR

VENT

Fig. 41—Rooftop Termination

(Dimension "A" is Touching or 2-In. Maximum Separation)

A96128

Fig. 45—Sidewall Termination of More Than 12 in.

(Dimension "A" is Touching or 2-In.

Maximum Separation)

A96130

COMBUSTION AIR

VENT

Fig. 43—Concentric Vent and Combustion-Air

Side Termination

(Dimension "A" is Touching or 2-In.

Maximum Separation)

A93057

COMBUSTION AIR

VENT

1″ MAXIMUM

(TYP)
