FURNACE CONTROL PROGRAMMING
AND NAVIGATION
On-Board Control Method
This furnace model is equipped with an on-board 3-digit LCD display
with pushbutton navigation for the adjustment of operating parameters,
diagnostics, and service. The control board must be powered to use the
display and pushbuttons. Upon startup, the control will alternate
displaying the Model Program Number (PRG) and Software Version
(uEr). The control board has been programmed at the factory with a
Model Program Number specific to the furnace product number. The
correct Model Program Number is shown on the furnace rating plate.
The system’s status is displayed after startup or after no control buttons
have been pressed for 60 seconds. Status Code LED will also be
illuminated or blinking when displaying the system status. The codes
which indicate the current operating mode of the system as shown in
Table 11.
Table 10 – Airflow Settings
Default Airflow Settings
*
*. Setting #1 is the default setting for Constant Fan
Designated Airflow Settings
Unit Size Heating Cooling Heating Constant Fan
045M14--12 8 18 (4-12) (1-7)
045M17--14 6 18 (4-12) (1-7)
070M14--12 15 18 (9-16) (1-7)
070M17--12 15 18 (11-17) (1-8)
070M17--16 12 18 (7-13) (1-4)
070M21--16 10 18 (6-14) (1-8)
090M17--14 12 18 (7-16) (1-9)
090M21--16 13 18 (8-16) (1-6)
090M24--20 11 18 (7-16) (1-10)
110M21--20 12 16 (8-15) (1-9)
110M24--20 15 18 (9-17) (1-6)
135M24--20 15 18 (12-16) (1-7)
CAUTION
!
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury, or death.
Blower access door switch removes 115-V power to control. No
component operation can occur unless switch is closed. Caution must
be taken when manually closing this switch for service purposes.
Do not tape or permanently allow the door switch to be bypassed.
Temporarily depress the door switch with one hand while accessing the
service buttons with your other hand. Do not touch uninsulated
electrical components.
Table 11 – System Status Display Codes
Display Operating Mode Notes
iDl
Idle/Standby Mode No active demands
Ht
Heating Mode Gas Heating active
CL
Cooling Mode Cooling or Heat Pump active
Hpd
Heat Pump Defrost Mode Gas Heating cycle active during Heat Pump Defrost cycle
Cfn
Continuous Fan Mode Continuous Fan active
bLr
Secondary Unit Operating
Blower
Only used when control is the secondary furnace of a twinned furnace system and
primary furnace is active
##.# Active Status Code See Fig. 45 or Furnace Service Label for codes
