13
7. Specification of electrical parts
7.1 Temperature-resistance of room temp. sensor & pipe temp. sensor
Temperature
℃
Resistance
KΩ
Temperature
℃
Resistance
KΩ
Temperature
℃
Resistance
KΩ
-10 62.28 17 14.618 44 4.3874
-9 58.71 18 13.918 45 4.2126
-8 56.37 19 13.263 46 4.0459
-7 52.24 20 12.643 47 3.8867
-6 49.32 21 12.056 48 3.7348
-5 46.57 22 11.5 49 3.5896
-4 44 23 10.973 50 3.451
-3 41.59 24 10.474 51 3.3185
-2 39.82 25 10 52 3.1918
-1 37.2 26 9.5507 53 3.0707
0 35.2 27 9.1245 54 2.959
1 33.33 28 8.7198 55 2.8442
2 31.56 29 8.3357 56 2.7382
3 29.91 30 7.9708 57 2.6368
4 28.35 31 7.6241 58 2.5397
5 26.88 32 7.2946 59 2.4468
6 25.5 33 6.9814 60 2.3577
7 24.19 34 6.6835 61 2.2725
8 22.57 35 6.4002 62 2.1907
9 21.81 36 6.1306 63 2.1124
10 20.72 37 5.8736 64 2.0373
11 19.69 38 5.6296 65 1.9653
12 18.72 39 5.3969 66 1.8963
13 17.8 40 5.1752 67 1.830
14 16.93 41 4.9639 68 1.7665
15 16.12 42 4.7625 69 1.7055
16 15.34 43 4.5705 70 1.6469
7.2 Compressor windings resistance (run & start winding @20℃)
Compressor model PG180X1C-4DZ3 PG225X2C-4FT PG330*2CS-4KU3
Winding 1 (Main)
3.33±5% 2.35±5% 1.54±5%
Winding 2 (Sub)
3.78±5% 3.22±5% 3.04±5%
7.3 Indoor fan motor windings resistance (@20℃).
Motor model RPG13H RPG20D RPG25
Winding 1 (Main)
400 327 209±8%Ω
Winding 2 (Sub)
430 380 376±8%Ω
