Carrier ALLEGRO 42HQE009N User Manual

32
Outdoor unit
Pos. Description Part No. 018
Guard fan 10321111044 1
Front panel 10924121801 1
Front cabinet assy, right 10118121803 1
Propeller fan 10118121804 1
Fan Motor 12818111807 1
Base pan assembly 10121121802 1
Foam, motor holder 10118121807 1
Cover assembly 10118121827 1
Holder for fan motor 10118121809 1
Separating board 10118111806 1
Small Handle 10109121802 1
Condenser coil assy 10218121801 1
Rear net 10924121809 1
Installation board left 10924121808 1
Right clapboard 10118113804 1
Big Handle 10118121817 1
Installation plate for valves 10118113805 1
Capacitor clamp 10112121814 1
Compressor capacitor 10312121813 1
Fan motor capacitor 10112121815 1
Electric installation plate 12818111803 1
Terminal block 10109121823 1
Washer for wire joint 10112121817 1
Wire clamp 10118121823 1
Liquid pipe valve assy 10218121805 1
Four-Way Valve assy 50418121805 1
Gas pipe valve 50118121803 1
Compressor 50418121806 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Models
38YE Notes
38YE018
( product. 2005)
