Carrier RTU Open v3 Integration Guide

Communications wiring
RTU Open v3 Carrier Proprietary and Confidential CARRIER CORPORATION ©2016
Integration Guide All rights reserved
11
Wire specifications
○ A dedicated 22 AWG shielded twisted pair wire (EIA 485)
○ Maximum wire length 2000 feet (610 meters) or 32 nodes
○ Devices should be daisy-chained and not star-wired
○ Attach the drain/shield wire to both ends of the network segment and through every controller
NOTE
Use the same polarity throughout the network segment.
7 Turn
on
the RTU Open's power.
Troubleshooting Modbus
Check the following to troubleshoot your RTU Open:
1 Verify that the BAS and controller are both set to speak the Modbus RTU protocol on the Comm Selector DIP
switches
DS3 - DS6
.
2 Verify that the BAS and the controller are both set for the same baud rate:
○ Baud rate DIP switches DS2 and DS1
○ Obtain a Modstat of the controller. Scroll to the bottom of the page to
Network Communications
to view
the active protocol and baud rate.
3 Verify that the BAS is configured to speak 2-wire EIA-485 to the controller. The BAS may have to configure
jumper or DIP switches on their end.
4 Verify that the BAS and the controller have the same communication settings (8 data bits, No Parity, and 1
stop bit).
5 Verify proper connection wiring between the BAS and the controller.
6 Verify that the rotary address switches are set for the controller's unique slave address.
7 BAS must be reading or writing to the proper point addresses on the controller.
8 BAS is sending requests to the proper slave address of the controller.
NOTES
• Refer to Appendix A (page 35) for the Network Points list.
• Refer to Appendix C (page 47) for the Protocol Implementation Conformance Statement.
Modbus Exception Codes that might be returned from this controller
Codes
Name
Description
01 Illegal Function The Modbus function code used in the query is not
supported by the controller.
02 Illegal Data
Address
The register address used in the query is not supported
by the controller.
04 Slave Device
Failure
The Modbus Master has attempted to write to a non-
existent register or a read-only register in the
controller.
