3. Insert the support cover into the
support as fig 3.
4. Attach the head to the support.
Insert and fasten stop bolt as fig 4.
fig. 3 fig. 4
OPERATIONS
1. General Weighing
■ When you turn on the power switch, the scale will count “00000” to “99999”.
Then the scale will read “0.00” in the weight display. This is called the ZERO state.
If the scale is not ZERO state though there is nothing on the platter, press the key.
■ The display indicates if the scale is at zero or if there is a tare entered into the
scale by way of a and NET lamps.
① Place the commodity on
the platter.
② Remove the commodity
from the platter.
