Operation Guide 5122
Setting Modes
The watch has a number of setting modes that you can use to configure its settings. In
the Timekeeping Mode, hold down A until the setting mode you want is selected as
described below. Release A when the setting mode you want is selected.
To select a setting mode
Hold down A.
x Second Hand moves to 12 o’clock.
(3 seconds)
x Second Hand moves to 1 o’clock, indicating the Home
City Setting Mode. See “To configure summer time and
other Home City settings”.
(3 seconds)
x Second Hand moves to 2 o’clock, indicating the Manual
Setting Mode. See “To change the current time setting
manually”.
(3 seconds)
x Second Hand moves to 3 o’clock, indicating the Home
Position Adjustment Mode. See “To adjust home positions”.
(3 seconds)
Watch returns to normal timekeeping.
If the •
x Second Hand home position is off due to the
watch having been subjected to strong magnetism or
other abnormal treatment, the second hand may point
to other positions than those described in the above
procedure.
Timekeeping
Use the Timekeeping Mode to view the current time and date. To enter the
Timekeeping Mode from any other mode, hold down C at least two seconds.
Hand Functions
z Hour Hand
x Second Hand
c Minute Hand
v Left Dial hand: Indicates TM.
b Right Dial Hands:
Indicate the current time in the World Time City
in 24-hour format.
n 24-hour Hand:
Indicates the current 24-hour timekeeping hour.
m Day
Configuring Home City Settings
There are two Home City settings: actually selecting the Home City and selecting
either standard time or daylight saving time (DST).
To configure summer time and other Home City
settings
Note
This watch does not have a city code that corresponds •
to Newfoundland.
Use 1. A as shown under “Setting Modes” to enter the
“Home City Setting” mode.
The watch will exit the setting mode automatically if •
you do not perform any operation for about two or
three minutes.
For details about city codes, see the “City Code •
Table” at the back of this manual.
To change the Home City setting, press 2. D to move the
x Second Hand clockwise.
Press • D as many times as necessary until the
x Second Hand is pointing at the city code you want
to select as your Home City.
Holding down • D causes the
x Second Hand to move
at high speed.
Each time you change the city code setting, the •
z Hour Hand, c Minute Hand, n 24-hour Hand and
m Day move to the current time and date for that city
code. Do not perform the next operation until these
hands stop moving.
Press 3. B to select AT (AUTO), STD (standard time), or DST (daylight saving time)
for the currently selected city code.
While you are selecting the Home City code, the •
v Left Dial hand will indicate
the setting (AT, STD, DST) of the currently selected city code.
Note that you cannot change the summer time setting while • UTC is selected as
your Home City.
The following explains each of the available summer time settings. −
AT (AUTO) This setting causes the watch to switch between standard time and
summer time automatically, in accordance with time calibration
signal data. This setting is available only when a city code that
supports signal reception is selected as the Home City.
STD
With this setting, the watch always indicates standard time. It does
not indicate summer time.
DST
With this setting, the watch advances its time setting by one hour
to indicate summer time (daylight saving time).
After all the settings are the way you want, press 4. A to return to the Timekeeping
Mode.
Note
After you specify a city code, the watch will use UTC* offsets to calculate the World •
Time based on the current time in your Home City.
Selecting some city codes makes it possible for the watch to receive the time •
calibration signal for the corresponding area automatically.
Coordinated Universal Time, the world-wide scientific standard of timekeeping. The *
reference point for UTC is Greenwich, England.
Configuring Current Time and Date Settings Manually
You can configure current time and date settings manually when the watch is unable
to receive a time calibration signal.
To change the current time setting manually
Use 1. A as shown under “Setting Modes” to enter the
“Manual Setting” mode.
The •
x Second Hand will move to 12 o’clock. This is
the time setting mode.
In the following steps, each press of • C cycles between settings as shown
below.
Hour/Minute
Year (tens digit)
Day Month
Year (ones digit)
Use 2. D (+) and B (–) to change the time (hour and
minute) setting.
Each press of either button will move the hands •
(
z Hour Hand and c Minute Hand) one minute.
Holding down • D or B will start high-speed z Hour
Hand and
c Minute Hand movement in the applicable
direction. To stop high-speed hand movement, press
any button.
The •
n 24-hour Hand and z Hour Hand move in sync
with each other.
When setting the time, make sure that the •
n 24-hour
Hand indicates the proper a.m./p.m. hour.
If you want to change the date setting at this time, •
press C and perform the procedure starting from
step 3 under “To change the current date setting
manually”.
After the time setting is the way you want, press 3. A to return to regular
timekeeping.
This will cause the •
x Second Hand to move automatically to 12 o’clock and
resume movement from there.
To change the current date setting manually
00
50
10
40
20
3090
60
80
70
Setting the year (tens digit)
Use 1. A as shown under “Setting Modes”
to enter the “Manual Setting” mode.
Press 2. C.
The •
x Second Hand will move to the tens digit of
the current year setting. This is the year setting
mode.
The year can be set in the range of 2000 to 2099. •
0
5
1
4
2
3
9
6
8
7
Setting the year (ones digit)
Press 3. D to move the x Second Hand clockwise
until it is pointing at the year tens digit you want
to select.
After you select the year tens digit, press 4. C.
The •
x Second Hand will move to the ones digit
of the current year.
Press 5. D to move the
x Second Hand clockwise
until it is pointing at the year ones digit you want
to select.
