— 9 —
4. GENERAL GUIDE and INITIAL SET UP
4.1. General Guide
Card slot
Stereo headphone jack
For connection of a
commercially available
earphone/headphones (ø3.5mm)
Stylus
Start button
(Program button)
Press to display
the Start menu.
Action control
See “About the
[Action] Control”
on the next page.
Record button
(Program button)
Voice memo recording is
activated as long as you
hold down this button.
Indicator lamp (Red)
Alerts you to alarms and
warning.
Touch screen
Perform operations and input
data by tapping and writing
directly on the screen.
Program buttons
Press to launch the
assigned program.
The programs
shown here are the
initial default
settings.
• Menu
(Launcher)
• Contacts
• Calendar
Speaker
Cursor button
Moves the cursor around
the screen.
Infrared port
Microphone
AC adapter terminal
Power button
Turns power on
and off.
Charge indicator (Amber/Green)
Lights amber when the battery pack is
charging and turns green when full
charge is achieved.
To Next Page
