Using the Mixer
E-41
The tables below show the parameters that can be configured on the mixer screen.
The settings marked with an asterisk (*) in the “Setting Range” column are initial defaults.
MASTER parameters include items for adjusting the volume level, pan position, and other settings that are applied globally to all
parts.
DSP parameters include DSP-related settings that are applied globally to all parts.
• DSP parameter setting cannot be changed while “on” is selected for the “DSP Disable” effect setting. See “To add the
chorus effect to sounds” (page E-31) for information about “DSP Disable”. If you want to change DSP parameter
settings, change the “DSP Disable” setting to “oFF”.
Mixer Parameter Settings
MASTER Parameters
Parameter Name Description Setting Range
Volume
(Master Volume)
Specifies the maximum volume level of Digital Keyboard output.
The level set here is the maximum level that can be set with the L-2 (VOLUME)
knob.
0 to 127
*
Pan
(Master Pan)
Specifies the stereo pan position of all sound output by the Digital Keyboard.
0 indicates the center, while a smaller values shifts to the left and a larger value
shifts to the right.
–64 to 0
*
to +63
DSP Parameters
Parameter Name Description Setting Range
Cho/DSP
(Chorus/DSP)
Specifies whether the Digital Keyboard’s sound source should go through
the chorus or DSP.
*1
This setting item is linked to the “Chorus/DSP”
*2
item
on the effect setting screen. The settings below cannot be configured
whenever this parameter is “Chorus”.
Chorus
*
, DSP
Part
(DSP Output Enable)
Specifies if a note should be output (on) or not output (oFF) after it passes
through the DSP.
oFF, on
*
Volume
(DSP Output Volume)
Specifies the post-DSP volume level.
*1
0 to 127
*
Pan
(DSP Output Pan)
Specifies the post-DSP send stereo pan position. 0 indicates the center,
while a smaller values shifts to the left and a larger value shifts to the right.
–64 to 0
*
to +63
Rev.Send
(DSP Output Reverb Send)
Specifies how much reverb is applied to the post-DSP send note. 0 to 40
*
to 127
*1 See the block diagram under “Configuration of Effects” (page E-29).
*2 See “To add the chorus effect to sounds” (page E-31) and “To use a DSP” (page E-32).
CTK7300IN_e.book 41 ページ ２０１３年７月１９日 金曜日 午後１２時１分

Casio CTK-7200 Specifications

General

Control type	Buttons, Touch
MIDI-keyboard number of keys	61 keys
Display type	LED
Built-in display	Yes
Product color	Black, White
Sound effects	Chorus, Equalization, Flanger/Digital Signal Processing (DSP), Reverberation
Compatible products	GM Compatibility: Level1
Maximum polyphony (notes)	64
Music memory capacity (songs)	16
Power source type	Battery, DC
Interface	USB
Headphone outputs	1
Cables included	AC

Weight and Dimensions

Depth	384 mm
Width	948 mm
Height	122 mm
Weight	6700 g
