Casio Exilim EX-H5 User Manual

108
Printing
You can connect the camera directly to a printer that supports PictBridge and print
images without going through a computer.
. To set up the camera before connecting to a printer
1. Turn on the camera. Next, press [SET] and then display the REC menu
(page 65) or the PLAY menu (page 89).
2. On the “Set Up” tab, select “USB” and then press [6].
3. Use [8] and [2] to select “PTP (PictBridge)”, and then press [SET].
. Connecting the Camera to a Printer
Use the USB cable that
comes bundled with the
camera to connect the
camera to your printer’s USB
port.
• The camera does not draw
power over the USB cable.
Make sure the camera’s
battery is sufficiently
charged before
connecting.
• Make sure that you insert
the cable connector into
the USB/AV port until you
feel it click securely into
place. Failure to insert the
connector fully can result
in poor communication or
malfunction.
• Note that even while the
connector is fully inserted, you still will be able to see the
metal part of the connector as shown in the illustration.
• When connecting the USB cable to a USB port, make sure
you align the connector correctly with the port.
Connecting Directly to a PictBridge Compatible Printer
USB cable
USB port
USB/AV port
Making sure that the 2 mark on the camera is aligned
with the 8 mark of the USB cable connector, connect
the cable to the camera.
Large connector
Small connector

Casio Exilim EX-H5 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CCD
Image sensor size	1/2.3 \
Supported aspect ratios	16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3264 x 2448, 4000 x 2240
Digital zoom	4 x
Optical zoom	10 x
Focal length range	4.3 - 43 mm
Lens structure (elements/groups)	11/10
Digital SLR	No
Built-in flash	Yes
Camera shutter speed	1/2 - 1/2000 s
Focal length (35mm film equivalent)	24 - 240 mm
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	0.5 - 2.4 m
Flash range (wide)	0.2 - 4.2 m
Internal memory	24.5 MB
Compatible memory cards	eye-fi, sd, sdhc
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Display diagonal	2.7 \
Display resolution (numeric)	230400 pixels
USB version	2.0
Product color	Red
White balance	auto, daylight, Fluorescent, manual, Shade, Tungsten
Camera playback	Movie
Battery life (CIPA standard)	240 shots
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Camera shutter type	electronic, mechanical
Light metering	Spot

Weight and Dimensions

Depth	29.1 mm
Width	103.5 mm
Height	59.4 mm
Weight	157 g
