— 13 —
7. TO FIX TAB ASS'Y
When fixing a TAB ass'y part to the main PCB, it is necessary to paint "Neji lock" after soldering the
cable to the place of soldering part for the against of a shock.
1) Parts code of "Neji lock"
Code No. Name Specification Unit Price (FOB:JAPAN)
0001 9829 Neji lock 1402B YEN1,590.-
2) Location of the painting part
TAB Ass'y
Painting place
To Next Page
