Casio V-R100 Service Manual

V-R100
– 47 –
1 V-R100-BD (DLS Europe)
2 V-R100-A (Australia)
3 V-R100-B (DI Europe)
4 V-R100-K (DI UK)
5 V-R100-C (US/Canada)
6 V-R100-DD (DLS UK)
7 V-R100-T (Taiwan)
1234567
RN Item Code No. Parts Name Specification
Q'ty
4. PR-ASSY
N 4-1 10399634 PRINTER/THERMAL FTP-638MCL401-R
1111111A
N 4-2 10413754 PCB ASSY/E840-PR RJE503755*001V01
1111111B
N 4-3 10409759 MOUNT/PR RJE503787-002V01
1111111X
S3 SCREW S-BDMA-3X4Z3
1111111X
S6 SCREW S-BDST-2X5Z3
2222222X
5. CHASSIS-ASSY
N 5-1 10413764 PCB ASSY/E840-IOC TK-RJE503753*001
1111111A
10225980 FUSE 230.600MXP
1111111B
N 5-2 10413762 PCB ASSY/E840-COM TK-RJE503758*001
1111111C
N 5-3 10413763 E840-ETH-UNIT TK-RJE503881*001
1111111C
N 5-4 10406954 CABLE/FFC/E840COM E441341-018V03
1111111C
N 5-5 10412269 CABLE-SUBASSY/DRAWER RJE503863*001V02
1111111C
N 5-6 10412270 CABLE-SUBASSY/DRAWER RJE502394*002V02
1111111C
N 5-7 10414065 PAD/RUBBER RJE503879-001V02
4444444X
N 5-8 10417480 PLATE/INSUL RJE503944-001V01 1111111X
S3 SCREW S-BDMA-3X4Z3 2222222X
S12 SCREW S-BDMA-3X6Z3 4444444X
6. DISPLAY-ASSY
N 6-1 10410052 COVER/CONNECTOR RJE503840-001V03
1111111C
N 6-2 10410051 COVER/SHEET RJE503841-001V02
1111111C
N 6-3 10409601 COVER/SD RJE503877-001V01
1111111C
N 6-4 10409756 COVER/BATTERY RJE503908-001V01
1111111X
N 6-5 10413757 BATTERY RJE503905*001V01
3333333B
S7 SCREW RJE503894-001V01
2222222X
S8 SCREW S-BD-PT-3X8B3
5555555X
S13 SCREW S-BDMA-3X8Z3 2222222X
7. F-CASE-ASSY
N 7-1 10419525 ASSY/TP TK-RJE503835*007 1111 1A
N 7-1 10419526 ASSY/TP TK-RJE503835*006 1 1A
N 7-2 10409537 LENS/LED RJE503847-001V01
1111111C
N 7-3 10409519 CHASSIS/LCD RJE503848-001V01
1111111X
N 7-4 10410050 CHASSIS/HNG RJE503849-001V02
1111111X
N 7-5 10399636 LCD G104SN02-V2
1111111A
N 7-6 10413765 PCB ASSY/E840-1 RJE503750*001V01
1111111A
N 7-7 10413766 PCB ASSY/E840-E61 RJE503751*001V01
1111111C
N 7-8 10413767 PCB ASSY/E840-E62 RJE503752*001V01
1111111C
N 7-9 10409550 CABLE/LVDS RJE503739*001V01
1111111C
N 7-10 10413625 CABLE/BL RJE503726*001V02
1111111C
N 7-11 10413629 IOS2 CABLE SUBASSY RJE503916*001V02 1111111C
N 7-12 10413627 CABLE/IOPW RJE503732*001V03
1111111C
N 7-13 10413189 CABLE/LAN RJE503733*001V05
1111111C
N 7-14 10413626 CABLE/E6 RJE503727*001V02
1111111C
N 7-15 10409528 BOX/BAT RJE503893*001V01
1111111C
N 7-16 10409546 SHEET/BAT RJE503903-001V01
1111111X
N 7-17 10409522 DALLAS-ASSY RJE503808-001V01 1 1 B
N 7-18 10409543 SPACER/DALLAS RJE503900-001V01 1 1 X
7-19 10073671 CORE/FERRlTE TR-20-10-10 1 1 X
S9 SCREW S-BDMA-3X5Z3
9999999X
S10 SCREW S-BD-PT-3X8Z3
7777777X
S11 SCREW S-BD-PT-2X6Z3
3333333X
