28 User Wave Parameter(XW-G1 only)
These parameters configure User Wave tone settings.
28.1 User Wave Key Splits Parameter (x10splits)
These parameters configure User Wave tone split settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Volume 0001 R/W 3-0:Split Number(0-4(L),5-9(R)) 7 01 00-7F-7F 0 - 127
Pan 0002 R/W ↑ 7 01 00-40-7F -64 - 0 - +63
Pitch Key 0003 R/W ↑ 7 01 00-40-7F Added to key number
as 0x40 center
Pitch Cent 0004 R/W ↑ 16 01 0000-0000-FFFF S------.- --------
S:sign bit
-------.c cccccccc
c:cent
= 100/512 cent
resolution
0000001.0
00000000...For +100
cent(1 semitone)
1111111.0
00000000...For -100
cent(1 semitone)
Cutoff 0005 R/W ↑ 7 01 00-00-7F 0-127
Touch Sense 0006 R/W ↑ 7 01 00-7F-7F -64 - 0 - +63
Key Follow 0007 R/W ↑ 8 01 00-C0-FF -128 - 0 - +127
Key Follow Base 0008 R/W ↑ 7 01 00-3C-7F 0-127
Pitch Envelope Depth 0009 R/W ↑ 7 01 00-40-7F -64 - 0 - +63
Init Level 000A R/W ↑ 7 01 00-40-7F -64 - 0 - +63
Attack Time 000B R/W ↑ 7 01 00-00-7F 0-127
Release Time 000C R/W ↑ 7 01 00-00-7F 0-127
Release Level 000D R/W ↑ 7 01 00-40-7F -64 - 0 - +63
Init Level 000E R/W ↑ 7 01 00-00-7F 0-127
Attack Time 000F R/W ↑ 7 01 00-00-7F 0-127
Attack Level 0010 R/W ↑ 7 01 00-00-7F 0-127
Decay Time 0011 R/W ↑ 7 01 00-00-7F 0-127
Sustain Level 0012 R/W ↑ 7 01 00-00-7F 0-127
Release1 Time 0013 R/W ↑ 7 01 00-00-7F 0-127
Release1 Level 0014 R/W ↑ 7 01 00-00-7F 0-127
Release2 Time 0015 R/W ↑ 7 01 00-00-7F 0-127
Release2 Level 0016 R/W ↑ 7 01 00-00-7F 0-127
Key Range Low 0017 R/W ↑ 7 01 00-00-7F 0 - 127
Key Range High 0018 R/W ↑ 7 01 00-7F-7F 0 - 127
Original Key 0019 R/W ↑ 7 01 00-41-7F Default F4
28.2 User Wave LFO Parameter
These parameters configure User Wave tone LFO settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Pitch LFO Wave Type 001F R/W 00000000 4 01 00-00-0F 0...Sin
1...Tri
2...Saw Up
3...Saw Down
4...Pulse 1:3
5...Pulse 2:2
6...Pulse 3:1
Pitch LFO Rate 0020 R/W ↑ 7 01 00-40-7F 0 - 127
Pitch Auto Delay 0021 R/W ↑ 7 01 00-00-7F 0 - 127
Pitch Auto Rise 0022 R/W ↑ 7 01 00-00-7F 0 - 127
Pitch Auto Depth 0023 R/W ↑ 8 01 00-80-FF -128 - 0 - +127
80
