Chamberlain ML1000EV User Manual

en 13/13
Service parts / Warranty
Please refer to www.chamberlain.eu or contact your local dealer.
Also refer to the available Warranty Book.
36
37
B. P. Kelkhoff
Manager, Regulatory Affairs
Chamberlain GmbH
Alred-Nobel-Str. 4
D-66793 Saarwellingen
February 2013
Declaration of conformity
The listed automatic garage door opener corresponds to the
applicable sections of the standards EN 55014-1 (2006), EN
55014-2 (2008), EN 61000-4-2 (2009), EN 61000-4-3 (2008),
EN 61000-4-4 (2004), EN 61000-4-5 (2007), EN 61000-4-6
(2009), EN 61000-4-11 (2004), EN 62233 (2008), EN 300220-
1 (V2.3.1),
EN 300220-2 (V2.1.2), EN 60335-1 (2010), EN 60335-2-95
(2004) in accordance with the provisions and all amendments
to the European Directives 2004/108/EC, 2006/95/EC,
2006/42/EC and 1999/5/EG.
Model: ...................................................ML700EV, ML1000EV
S./N.: ............................................xxxxx000001 - xxxxx99999
Manufacturer ........................................Chamberlain GmbH
...........................................Alfred-Nobel-Str. 4
...................................D-66793 Saarwellingen
All technical archive data for the opener and the associated
accessories are kept safe by Chamberlain GmbH and will be
provided to the authorities on request if required.
Declaration of conformity
Specifications
Input Voltage...................230-240 VAC, 50 Hz
Max. Pull Force ..............700 N (COMFORT), 1000 N (PREMIUM)
Standby Power
(door fully closed)...........0.8 W
Motor
Type................................DC gearmotor permanent lubrication
Noise level......................54dB
Drive Mechanism............Belt
Length of Travel..............Adjustable
Opening speed, up to ....160 mm/s (COMFORT), 200 mm/s (PREMIUM)
Lamp...............................On when door starts, off 2-1/2 minutes
after stop.
Door Linkage ..................Adjustable door arm. Pull cord trolley release.
Safety
Personal .........................Push button and automatic stop in down
direction. Push button and automatic stop in
up direction.
Electronic........................Automatic force adjustment
Electrical .........................Transformer overload protector and low
voltage push button wiring.
Limit Device ....................Mechanical RPM/Passpoint detector.
Limit Adjustment .............Electronic
Soft-Start / Soft-Stop........all
Dimensions
Length (Overall)...............3200 mm
Headroom Required .......30 mm
Hanging Weight ..............~12 kg
Receiver
Memory Registers ..........180
Operating Frequency.......6-Band (433 MHz / 868 MHz)
SPECIAL NOTE: Chamberlain strongly recommends installing photocells
on all garage door openers.
35

Chamberlain ML1000EV Specifications

General

Operating temperature (T-T)	-30 - 65 °C
Speed	200 mm/sec
Frequency	433 MHz
Drive type	-
Product color	Gray
Headroom (min)	30 mm
Maximum door area	13.5 m²
Maximum door height	2200 mm
Maximum weight capacity	130 kg
Input voltage	230 - 240 V
Input frequency	50 Hz
Power source type	AC
Quantity	1

Weight and Dimensions

Depth	3200 mm
Weight	12000 g
