Chenbro SR301 series User Manual

4-port 12Gb/s SAS/ SATA Backplane - 80H10230101A0 User Manual
Figure 1. Component Side of Backplane
Figure 2. Solder Side of Backplane
SW1, DIP Switch
CN02, Power Connector
CN01, Power Connector
JC01, I2C Connector
JF01, 4-pin Fan Header
JA01, Reserved
JP01, SGPIO mode Jumper
CB1, mini-SAS HDD Connector
JP02, Fail LED Header
JM1
JP1
B1, Buzzer (Reserved)
CH041
CH031
CH021
CH011
SAS/SATA HDD Connector
