6-20
Reinstalling the Engine Cover
1. Lift the engine cover into the front of the vehicle
and slide it all the way forward. Make sure the
rubber seal is over the latches.
2. Tighten the two bolts located on the engine cover
to reinstall the cover to the front of the dash.
3. Put the heater duct over the engine cover studs.
Push up on the duct gently until it snaps into place.
4. Reconnect the electrical connectors.
5. Reconnect the AM radio ground strap.
6. Reinstall the engine cover extension by gently
squeezing the sides and sliding it into place.
Make sure all of the fastener clips engage and the
extension fits properly in place. Reinstall and tighten
the two screws.
7. Reinstall the two nuts to secure the extension
in place.
Engine Air Cleaner/Filter
Refer to the Maintenance Schedule to determine when
to replace the engine air cleaner/filter and the crankcase
ventilation filter. See “Scheduled Maintenance” in
the Index.
See “Engine Compartment Overview” in the Index for
more information on location.
