2-13
To replace the battery, do the following:
1. Insert a thin object like a dime to separate the bottom
of the transmitter from the top.
2. Remove the battery and replace it with a new one,
making sure the positive (+) side of the battery is
facing down. Use one Panasonic
R
three-volt,
type CR2032, or equivalent battery.
3. Snap the top and bottom together.
Sliding Door
To open the sliding side door, pull the handle toward the
back and slide the door to the rear until it rests in the
open position.
To close the sliding side door, pull the handle toward the
front and slide the door forward.
