10-28 Vehicle Care
Fog Lamps
To replace one of these bulbs:
1. Locate the fog lamp assembly
under the front fascia.
2. Remove the bulb from the lamp
assembly by turning it
counterclockwise and pulling
straight out.
3. Disconnect the electrical
connector.
4. Reverse Steps 2 and 3 for
assembly.
Taillamps, Turn Signal,
Sidemarker, Stoplamps,
and Back-Up Lamps
1. Sidemarker
2. Stoplamp/Turn Signal Lamp/
Taillamp
3. Back-up Lamp
To replace one of these lamps:
1. Open the liftgate. See Liftgate
on page 2-9.
2. Remove the two screw covers
from the taillamp assembly.
3. Remove the two screws
securing the taillamp assembly.
4. Pull the taillamp assembly out of
the vehicle body.
5. Disconnect the lamp wiring
harness.
