Cisco 1841 Integrated Services Router with AIM-VPN/BPII-Plus and Cisco 2801 Integrated Services Router with AIM-VPN/EPII-Plus
OL-8719-01
Cisco 1841 and Cisco 2801 Routers
Table 6 describes the meaning of Ethernet LEDs on the front panel:
The physical interfaces are separated into the logical interfaces from FIPS 140-2 as described in the
Table 7:
Compact Flash Solid Green
Off
Indicates that the flash is busy and should not be removed.
OK to remove flash card.
PVDM1 Solid Green
Solid Orange
Off
PVDM1 installed and initialized.
PVDM1 installed and initialized error.
PVDM1 not installed.
PVDM0 Solid Green
Solid Orange
Off
PVDM0 installed and initialized.
PVDM0 installed and initialized error.
PVDM0 not installed.
AIM1 Solid Green
Solid Orange
Off
AIM1 installed and initialized.
AIM1 installed and initialized error.
AIM1 not installed.
AIM0 Solid Green
Solid Orange
Off
AIM0 installed and initialized.
AIM0 installed and initialized error.
AIM0 not installed.
Table 5 Cisco 2801 Front Panel Indicators (Continued)
Table 6 Cisco 2801 Ethernet Indicators
Name State Description
Duplex Solid Green
Off
Full-Duplex
Half-Duplex
Speed Solid Green
Off
100 Mbps
10 Mbps
Link Solid Green
Off
Ethernet link is established
No link established
Table 7 Cisco 2801 FIPS 140-2 Logical Interfaces
Router Physical Interface FIPS 140-2 Logical Interface
10/100 Ethernet LAN Ports
HWIC/WIC/VIC Ports
Console Port
Auxiliary Port
Data Input Interface

Cisco 1841 Specifications

General

Flash memory	32 MB
Internal memory	128 MB
Product color	Black, Blue, Stainless steel
Rack capacity	1U
LED indicators	Yes
Storage temperature (T-T)	-25 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Cabling technology	10/100Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	2
Firewall security	Cisco IOS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES
Dual-band	No

Weight and Dimensions

Depth	274 mm
Width	343 mm
Height	47.5 mm
Weight	2800 g
