Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Next-Generation High-Density PVDM3 Modules
Information About Configuring the PVDM3 Module on Cisco Voice Gateway Routers
DSP Image for the PVDM3
The DSP image for the PVDM3 supports all features supported on PVDM2 except Cisco Fax Relay. The
DSP image provides feature capability to implement the signal processing layer for a TDM-to-IP
gateway:
• TDM-to-IP gateway for voice telephony, including support for multicast conferencing through the
mixing of multiple IP streams out a single TDM port.
• Low-level processing of CAS from a T1/E1 interface through the use of digital signaling channels.
• Control and low-level processing of the signaling for analog telephony interface implemented on
Cisco’s voice interface card (VIC) hardware.
• Support for Voice Band Data (VBD) through the use of upspeeding channels.
• Support of facsimile using T.38 Fax Relay technology.
• Support of high-speed modems (V.32 and V.34) using Modem Relay technology.
• Interface with Secure Telephony (STU) phones using Secure Telephony over IP standard
technology.
• Support for interfacing VoIP channel to Land Mobile Radio (LMR) networks.
• Support for secure VoIP through the implementation of SRTP for both encryption and authentication
of RTP packets.
• Support for text telephony (Baudot) using Text Relay technology.
The DSP image for the PVDM3 also provides a complete set of features to implement the signal
processing layer of an IP-to-IP gateway and an IP-based conference server. Highlights of this
functionality include:
• G.711 transcoding for implementing a LAN-WAN gateway.
• Universal Transcoding between any two voice codecs (narrowband or wideband).
• Trans-scripting services for conversion between SRTP configurations or between secured and
unsecured networks.
• IP-based voice conferencing, including narrowband and wideband participants.
DSP ID 1,2 23,24,25,26,27,28 29 —
Device ID — 2,2,2,3,3,3 — —
Table 2 Example of a DSP Numbering Scheme for PVDM3 Only, PVDM2 Only, and Mixed
Installation (continued)
PVDM3 Only
PVDM slot 0 PVDM slot 1 PVDM slot 2 PVDM slot 3
PVDM3-256 PVDM3-16 PVDM3-64 PVDM3-192

Cisco 2901 Specifications

General

Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Ethernet LAN	Yes
Cabling technology	10/100/1000BASE-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
Ethernet LAN (RJ-45) ports	2
Firewall security	Cisco IOS
Input current	1.5 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	40 W
Product color	Black
Rack capacity	1U
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Flash memory	256 MB
Internal memory	512 MB
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	439.4 mm
Width	438.2 mm
Height	44.5 mm
Weight	6100 g
