Cisco 3200 Series Hardware Upgrade Guide

1-2
Cisco 3200 Series Router Hardware Upgrade Guide
OL-15983-01
Chapter 1 Introduction
Cisco 3230 Rugged Enclosure
Fully Assembled Cisco 3230 Rugged Enclosure
Figure 1-1 shows two views of a fully assembled Cisco 3230 Rugged Enclosure.
Figure 1-1 Cisco 3230 Rugged Enclosure
Exploded View of the Cisco 3230 Rugged Enclosure
Figure 1-5 shows an exploded view of the Cisco 3230 Rugged Enclosure.
1 Front of the enclosure (I/O end cap)
1
1. This end cap shows four serial ports, but the typical configuration has two serial ports.
2 Back of the enclosure (antenna end cap)
270442
2
1
