Page #10 background image
1-4
Cisco Video Surveillance 6030 IP Camera Installation Guide
OL-28492-02
Chapter 1 Overview
IP Camera Physical Details
5 Recessed Reset button Recessed button that reboots the IP camera or resets it to a
default state. You can use a pin or paper clip to depress it. It can
be used any time that the IP camera is on and can have various
effects, as described in the “Resetting the IP Camera” section
on page 2-11.
6 Microphone and Video Output
switches
Microphone
Internal (up)—switches to the built-in internal microphone
on the IP camera. Support for the internal microphone will
be in future releases.
External (down)—switches to the external Microphone In
connector.
Video Output
NTSC 60Hz (up)—switches camera operation to the
National Television System Committee (NTSC) standard.
PAL 50Hz (down)—switches camera operation to the
Phase Alternating Line (PAL) standard.
7 SD/SDHC card slot Support for the SD/SDHC card slot will be available in future
releases.
8 Audio/Video out (green) Allows the connection of an optional Y cable or mini cable with
BNC connector. You can connect a video monitor to the mini
cable with BNC connector. Both cables are included in the
optional audio/video cables accessory kit can be purchased
from Cisco (Cisco part number CIVS-AVCABLE).
Note Support for audio will be in future releases.
9 Microphone In (pink) Connection for an external microphone.
10 Ethernet 10/100 RJ45 socket Accepts a standard LAN cable to connect the IP camera to a
10/100BaseT router or switch.
11 General Purpose I/O Terminal
Block
General purpose input/output (GPIO) terminal block that is
used to connect external input and output devices. For more
information, see
Figure 1-2.
