Configure the Key Expansion Module with the Phone Web Interface
You can add number of supported key expansion modules from the phone web interface.
You can also configure the parameters in the phone configuration file with XML(cfg.xml) code.
Before you begin
Access the phone administration web page. See Access the Phone Web Interface.
Procedure
Step 1 Select Voice > Att Console.
Step 2 From the Number of Units list, select the number of supported key expansion modules.
You can also configure the parameter in the configuration file (cfg.xml) by entering a string in the following
format:
<Number_of_Units ua="na">2</Number_of_Units>
Default: 0
Step 3 Click Submit All Changes.
Access Key Expansion Module Setup
After you install one or more key expansion modules on the phone and configure them in the Configuration
Utility page, the phone automatically recognizes the key expansion modules.
When multiple key expansion modules are attached, they are numbered according to the order in which they
connect to the phone:
• Key expansion module 1 is the expansion module closest to the phone.
• Key expansion module 2 is the expansion module in the middle.
• Key expansion module 3 is the expansion module farthest to the right.
When the phone automatically recognizes the key expansion modules, you can then choose the Show Details
softkey for additional information about the selected key expansion module.
Procedure
Step 1 On the phone, press Applications .
Step 2 Press Status > Accessories.
All properly installed and configured key expansion modules display in the list of accessories.
