Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
Configuration Examples for Channelized SONET
HC-354
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Configuration Examples for Channelized SONET
This section contains the following examples:
• Channelized SONET Examples, page 354
• Channelized SDH Examples, page 356
Channelized SONET Examples
• Channelized SONET T3 to T1 Configuration: Example, page 354
• Channelized Packet over SONET Configuration: Example, page 355
• SONET Clear Channel T3 Configuration: Example, page 355
• Channelized SONET APS Multirouter Configuration: Example, page 355
Channelized SONET T3 to T1 Configuration: Example
The following example shows SONET T3 to T1 configuration.
configure
controller sonet 0/1/1/0
clock source internal
framing sonet
sts 1
mode t3
width 3
root
controller t3 0/1/1/0/0
mode t1
root
controller t1 0/1/1/0/0/0
framing esf
channel-group 0
timeslots 1:3:7:9
show configuration
root
interface serial 0/1/1/0/0/0:0
encapsulation hdlc
ip address 10.10.10.10 255.255.255.255
no shutdown
commit
show controllers sonet 0/1/1/0
Channelized SONET in VT1.5 Mode and T1 Channelization to NxDS0
Note This example is not supported on the 1-Port Channelized OC-48/STM-16 SPA.
The following example shows how to configure SONET channelized to NxDS0s through SONET VT1.5
mode:
configure
controller sonet 0/1/1/0
clock source internal
framing sonet
