Cisco ASR 903 Troubleshooting

DescriptionColor/StateLED
Fan rotation in rangeGreenFan (FAN)
Single fan faultAmber
Two or more fan faultsRed
No minor alarmOffMinor (MIN)
Minor alarmAmber
No major alarmOffMajor (MAJ)
Major alarmRed
No critical alarmOffCritical (CRIT)
Critical alarm (defaults to ON upon
RSP reset)
Red
Alarm Conditions
The table below summarizes the meaning of alarm conditions on the Cisco ASR 903 Router.
Table 32: Alarm Condition Summary
Alarm DescriptionAlarm Type
RSP OIRCritical
Power supply OIR
Port in down state
Environmental sensor threshold exceeded (voltage,
temperature)
IM OIR
IM crash
Standby RSP in ROMmon modeMajor
RSP removed
RSP failure
Cisco ASR 903 Aggregation Services Router Hardware Installation Guide
29
Troubleshooting
Alarm Conditions
