Ground Lug2
Figure 49: Chassis Ground Connection-Cisco 1121X-8PLTEP
Screw (UNC 6-32)1
Ground Lug2
Connect Power Cable
Power supply of the Cisco 1000 Series ISRs is an external AC to DC power adapter. The external DC power
connector plugs into the router's 4 points power connector.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
47
Install and Connect the Router
Connect Power Cable
