Figure 6: Cisco Catalyst 9600 Series 48-Port 25 G/10 G/1 G (C9600-LC-48YL)
Table 5: Front Panel Components
RFID embedded on the left ejector lever5Status LED1
Ejector levers6Locate (Blue beacon) LED2
Port Link LED for the port in the top row7Sharp-edge hazard icon3
Port Link LED for the port in the bottom
row
825 G/10 G/1 G SFP28/SFP+ ports4
Table 6: Features Supported on Cisco Catalyst 9600 Series 48-Port 25 G/10 G/1 G (C9600-LC-48YL)
DescriptionFeature
48 SFP28/SFP+ ports of 25 G, 10 G, and 1 G: Provides 48 25
G, 10 G, or 1 G interfaces by default. These ports can be
interchangeably used as 25 G, 10 G, and 1 G ports.
All the 48 ports support 25 G, 10 G, or 1 G speeds.
Ports per module
Cisco Catalyst 9600 Series Line Card Installation Note
5
Cisco Catalyst 9600 Series 48-Port 25 G/10 G/1 G (C9600-LC-48YL)
