Installing the Power Cord Retainer (Optional)
This section applies to switches with an AC power connector.
Note
Before you begin
• The power cord retainer (C9K-CMPCT-PWR-CLP) is optional. You can order it when you order your
switch, or you can order it later from your Cisco representative.
Procedure
Step 1 Fix the power cord retainer strap to the switch using the M3 pan-head screw provided.
Figure 24: Attaching the Power Cord Retainer Strap
Power cord retainer strap2M3x6mm pan-head screw1
Step 2 Slide the retainer clamp around the AC power cord and position it closest to the connector on the adapter.
Depending on the width of the power cord, adjust the size of the retainer clamp, if required.
Note
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
41
Installing a Compact Switch
Installing the Power Cord Retainer (Optional)
